Lan Posts - Advantech EPC-R7200 Manual

USB 1 & 2
Pin
1
3
5
7
9
10
12
14
16
18
2.3.3.

LAN Posts

EPC-R7200 supports 2 x 10/100/1000Mbps LAN ports on the front side.
LAN 1 is the Ethernet function from Intel I210 PCIE to GbE (NOT support on Jetson NANO)
LAN2 is the the Ethernet function from NVIDIA Jetson integrated RGMII
LAN1:
Pin
1
3
5
7
9
Pin Name
+VBUS_1
USB1_D+
USB1_SSRX-
GND
USB1_SSTX+
+VBUS_2
USB2_D+
USB2_SSRX-
GND
USB2_SSTX+
Pin Name
LAN1_MDI0+
LAN1_MDI1+
GND
LAN1_MDI2+
LAN1_MDI3+
11
Pin Pin Name
2 USB1_D-
4 GND
6 USB1_SSRX+
8 USB1_SSTX-
11 USB2_D-
13 GND
15 USB2_SSRX+
17 USB2_SSTX-
Pin Pin Name
2 LAN1_MDI0-
4 LAN1_MDI1-
6 GND
8 LAN1_MDI2-
10 LAN1_MDI3-
