Advantech EPC-R7200 industrial-grade barebone PC is equipped with a production carrier board
that is fully compatible with three types of Jetson modules in terms of form-factor and pin
configuration. Designed to serve as a complete industrial-grade system, EPC-R7200's high-quality
aluminum housing with improved heat dissipation and ESD protection provides the optimum
protection. Moreover, EPC-R7200's thermal solutions accommodate modular and module-specific
heat spreaders. This enables developers to adopt thermal solutions based on the Jetson module
they applied.
1.2.1.
Model Name
Compatible Modules NVIDIA Jetson
Graphics
Ethernet
Indicator
Button
Front I/O
Rear I/O
Expansion
Internal I/O
Power
Introduction
Product Features
Specification
HDMI
Engine
H/W Video Codec
Chipset
Speed
LED
USB
GbE
M.2
SD
SIM
Antenna Holes
Programing I/O
Camera I/O
Voltage
EPC-R7200
Nano / TX2 NX / Xavier NX
1 x HDMI 2.0, Maximum Resolution 3840 x 2160 at 60Hz
NVIDIA Maxwell GPU / Pascal GPU / Volta GPU on Jeston Modules
Up to 4K encode/decode
NVIDIA Jetson integrated RGMII and Intel 1GbE Controller
2 10/100/1000 Mbps
1 x Power LED; 1 x programmable LED
1 x Reset Button
2 x USB3.2 Gen 1 Type A
2 x RJ45 for GbE
Depends on UIO Expansion Board
1 M.2 2230 Key E Slot (USB2.0/PCIe/UART/I2S)
1 M.2 3042 Key B Slot (USB3.0/I2C)
1 Micro SD Socket
1 Nano SIM Slot
4
1 USB OTG
1 Console Port
1 Recovery Key
2 MIPI-CSI
9-24V DC
4
