2.4.2.
OTG port
EPC-R7200 supports 1 USB 2.0 OTG port (Device mode ONLY) for development purpose.
USB OTG:
Pin
1
3
5
2.4.3.
Micro SD
EPC-R7200 supports 1 Micro SD socket (SDHC/SDXC)
Pin Name
+VBUS_5V
USB_D+
GND
14
Pin
Pin Name
2
USB_D-
4
GND
Table of
