Module
Conn./Pin
Color
Description
H2/19
Blue
(-) Trunk Input
H2/20
Green
(-) Door Input
H2/21
Gray
(-) Hood Input
H2/22
Violet/White
(AC) Tach Input
Main harness, 12-pin black connector (H3)
Module
Conn./Pin
Color
Description
H3/1
Blue/White
Relay 1 N.C. - No Connection
H3/2
Blue/Red
Relay 1 N.O. - (+) 12 Volt Input
H3/3
Blue
Relay 1 COM - (+) Ignition Output
H3/4
White/Brown
Relay 3 N.C. - No Connection
H3/5
White
Relay 3 COM - (+) Parking Light Output
H3/6
Red
(+) 12 Volt Input
H3/7
Lt. Green/Red
Relay 2 N.O. - (+) 12 Volt Input
H3/8
Lt. Green
Relay 2 COM - (+) Starter Output
H3/9
Lt. Green/White
Relay 2 N.C. - No Connection
H3/10
Black
(-) Ground
H3/11
White
Relay 3 COM - (+) Parking Light Output
H3/12
Red
(+) 12 Volt Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin
Color
Description
H4/1
N/A
No Connection
H4/2
Red/Black
(+) 12 Volt Input
H4/3
Pink/Black
Flex Relay (pin 87A)
H4/4
Pink/White
(+) Flex Relay Output
H4/5
Red
(+) 12 Volt Input
H4/6
Green
Starter Input (conn. side)
H4/7
Violet
(+) Starter Output (vehicle side)
H4/8
Orange
(+) Accessory Output
H4/9
Red/White
(+) 12 Volt Input
H4/10
Pink
(+) Ignition Input/Output
9
933.CHRYSLER 7.34.195.3 2005 Chrysler 300/300c
©2022 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
No Connection
No Connection
[1]
No Connection
Connects To
Wire Location
No Connection
passenger kick, harness to rear
ignition switch, black 5 pin plug, pin 3
No Connection
passenger kick, harness to rear
passenger kick, harness to rear
passenger kick, harness to rear
ignition switch, black 5 pin plug, pin 4
No Connection
Sentry Key Module on ignition switch, black 8 pin plug, pin 4
passenger kick, harness to rear
passenger kick, harness to rear
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-)
Wire Color
Connection
(+/-)
Wire Color
Connection
+
red/white (40A)
Remote Start
Only
+
pink/white
Remote Start
Only
+
white/violet
Mandatory
+
red/white (40A)
Mandatory
+
red/white (40A)
Remote Start
Only
+
pink/dk. green
Remote Start
Only
-
black/tan
Mandatory
+
white/violet
Mandatory
+
red/white (40A)
Mandatory
(+/-)
Wire Color
Connection
