Device Management
3.2 Configuring the Device
RJ45 Male
a
The DSR, DCD and DTR pins are connected together internally.
b
The CTS and RTS pins are connected together internally.
c
RI is not connected.
Communication Ports
Connect any of the available Ethernet ports on the device to a management switch
and access the RUGGEDCOM RSG2100F console and Web interfaces via the device's
IP address. For more information about available ports, refer to
Ports (Page
3.2
Configuring the Device
Once the device is installed and connected to the network, it must be configured.
All configuration management is done via the RUGGEDCOM RSG2100F interface.
For more information about configuring the device, refer to the "RUGGEDCOMROS
Configuration Manual" associated with the installed software release.
22
Pin
DB9 Female
8
7
1
9
23)".
Name
Description
b
RTS
Read to Send
c
RI
Ring Indicator
Comment
"Communication
RUGGEDCOM RSG2100F
Installation Manual, 04/2022, C79000-G8976-1344-11
