Communication Ports
4.3 SFP Transceivers
1
1
2
Figure 4.5
1
1
2
Figure 4.7
For specifications on the available fiber optic Ethernet ports, refer to
Ethernet Port Specifications (Page
4.3
SFP Transceivers
The RUGGEDCOM RSG2100F supports up to two Small Form-Factor Pluggable (SFP)
transceiver sockets, which are compatible with a wide array of SFP transceivers
available from Siemens.
LEDs
Each socket features an LED that indicates its link state.
Yellow (Solid)
Yellow (Blinking)
Off
Compatible SFP Transceivers
For more information about which SFP transceivers are compatible with the
RUGGEDCOM RSG2100F, as well as instructions for ordering and installation/
removal, refer to the
support.industry.siemens.com/cs/ca/en/view/109482309]".
26
2
Tx Connector
Rx Connector
MTRJ Port
Tx Connector
Rx Connector
SC Port
State
"RUGGEDCOM SFP Transceiver Catalog [https://
1
Tx Connector
1
Rx Connector
2
Figure 4.6
2
1
Tx Connector
1
Rx Connector
2
Figure 4.8
33)".
Link established
Activity
No link detected
2
LC Port
2
ST Port
"Fiber Optic
Description
RUGGEDCOM RSG2100F
Installation Manual, 04/2022, C79000-G8976-1344-11
