Module Programming - Directechs Directed DB3 Installation Manual

Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Wait until the LED turns ON solid red.
1
Note: To skip the transponder programming and use convenience features only, press the
programming button 5 times. When the LED turns ON solid orange, proceed to step 4.
Remove battery from one key fob, and make sure that the other key fob is located more than
2
10 feet away from vehicle.
3
Put the key fob (with battery removed) in the keyport. (Refer to Keyport location).
Press and hold the Push-to-Start (PTS) button until the ignition turns ON, then release. The
LED flashes orange then green.
Note: If the LED starts flashing 2x red, press and hold the Push-to-Start (PTS) button with the
4
brake pedal applied. When the engine begins cranking, let go of the button. The LED flashes
orange then green, proceed to step 5.
Note: If the transponder programming was skipped, the LED turns ON solid orange for 3
seconds then shuts OFF when programming is done.
5
Press the PTS button once to turn the ignition OFF. The LED will flash orange slowly.
Remove the module from the vehicle and reconnect it to your computer. The web site will
6
automatically recognize that you are moving onto the second phase of the programming
sequence.
7
Click on Submit Key2GO Request.
Once the configuration is completed, reconnect the module. The LED turns ON solid green for
8
3 seconds, then turns OFF.
You have successfully completed the module programming sequence.
12
403.GM9 2.42 2011 Buick LaCrosse (Smart Key)
