Installation Instructions
REV 2 01/28/14
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
FRONT
Part No.
2217
Product: Running Boards
Honda Ridgeline 205 - 2014
Level of Difficulty:
Installation Time: 60 min
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
1
2 3 4 5
Advertisement
Related Manuals for Romik 2217
Summary of Contents for Romik 2217
- Page 1 Part No. 2217 Product: Running Boards Honda Ridgeline 205 - 2014 Installation Instructions Level of Difficulty: 2 3 4 5 Installation Time: 60 min REV 2 01/28/14 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 3 Important Install Tip: When installing Romik HTC inserts follow the sequence below. Make sure the HTC is seated correctly and do not use power tools as this will only spin the insert and possibly damage it. Test by tugging on it before installing braket.
- Page 4 NOTE: Use of power tools will damage the bottom of the running board and void your warranty. 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1.
