Technical Data

Film transport
Film formats
Processing capacity
Processing time
Linear speed
Developer time
Tank capacities:
Circulation system
Replenishment
Developer temperature
Fixer temperature
Dryer temperature
Water connection
Water consumption
Drain capacity
Noise level
Heat emission
Pollution degree
Weight (processor)
Dimensions (LxWxH)
Floor space required
PROTEC GmbH & Co. KG, In den Dorfwiesen 14, 71720 Oberstenfeld, Germany
COMPACT 2 Instructions for use
Continuous roller transport system
In general: sheet films up to max. 45.1cm (17.7'')
width;
Smallest film format 10x10 cm (4x4'').
232 films 24x30 cm (10x12 ") per hour (standard
model, film fed in crosswise, at 90sec)
1 -5 min.; adjustable in steps of 0.1-min.
30 - 151 cm/min., depending on selected process
time
14 - 71 sec, depending on selected process time
12.5 l developer, 12 l fixer, 13l water
Developer and fixer are continuously circulated by a
circulation pump
Automatic by film surface measurement in relation
to processed film; quantity adjustable; time
replenishment can be activated.
Adjustable 26 - 40 °C (78.8 - 104 °F)
Adjusted to developer temperature by heat
exchanger
Adjustable 35 -70C° (95-158°F), temperature
achieved depends on main voltage
Permissible water pressure 2 - 10 bar (29 - 145 psi),
permissible water temperature 5 - 30 °C (41 - 86 °F)
1.9 litres per minute (0.5 gal/min) when processing.
11 litres per minute
Less than 59 dB(A)
During processing approx. 1.5kJ/s.
2
Empty 77 kg/*91kg (170/*200 lbs)
Filled 115 kg/*129 kg (254/*284 lbs)
97 x 68 x 127cm (38.2x26.8x50")
0.67 m² (7.2 sqft)
