THE WORLD MODELS Zero Fighter 60S Instruction Manual

THE WORLD MODELS Zero Fighter 60S Instruction Manual

0.60-0.75 cu. in. displacement 2-stroke
Hide thumbs Also See for Zero Fighter 60S:

Advertisement

Quick Links

Zero Fighter 60S
0.60-0.75 cu. in. displacement 2-stroke
Requires : 6-channel radio w/ 6 standard servos
Wing Span
Wing Area
Flying Weight
Fuselage Length
Wa rning ! This m ode l is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of engine powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual
at hand for quick reference.
The World Models
Manufacturing Co., LTD.
www.theworldmodels.com
A064SPO29991407
All manuals and user guides at all-guides.com
and 1 low profile retract servo
Specifications
* Specifications are subject to change without notice.*
60.0 in / 1520 mm
635 sq in / 41.0 sq dm
7.5 lbs / 3400 g
45.5 in / 1150 mm
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
INSTRUCTION MANUAL
(A064S)
MADE IN CHINA

Advertisement

loading
Need help?

Need help?

Do you have a question about the Zero Fighter 60S and is the answer not in the manual?

Questions and answers

Summary of Contents for THE WORLD MODELS Zero Fighter 60S

  • Page 1 All manuals and user guides at all-guides.com INSTRUCTION MANUAL Zero Fighter 60S (A064S) 0.60-0.75 cu. in. displacement 2-stroke Requires : 6-channel radio w/ 6 standard servos and 1 low profile retract servo Specifications Wing Span 60.0 in / 1520 mm Wing Area 635 sq in / 41.0 sq dm...
