THE WORLD MODELS Zero Fighter 60S Instruction Manual page 5

4 Aileron Servo
Screw
PB2x12mm
2
Screw
PB2x16mm
4
TWM PL8210010
CLEVIS WRENCH
5
Main Wing
Peel off shaded portion
covering film for lead to
another aileron servo
6 Retractable Landing Gear Servo
LINKAGE CONNECTOR
Set Screw
3 x 3mm
2
Linkage Connector
2
Nut
2mm
2
Washer
2mm
4
All manuals and user guides at all-guides.com
Ø1mm pilot holes for The
Please look for pin-hole marks at under side of control surfaces.
PB2x12mm
PB2x16mm
Clevis
Tri-Horn
Fuel Tube
M3x14mm
Ø6x5mm
Pushrod Ø1.8x90mm
Bottom View
Please apply glue to all surfaces of wing Joiner.
Wing Joiner
1mm
P.4
World Models tri-horn are pre-drilled.
Peel off shaded
portion covering film.
For Flap Servo
Lead to Aileron Servo
To R-side
To L-side
Wheels down position
Fuel Tube
Straper
6x5mm
Ø
Wheels up position
