Protouch2 GUI User Manual
usb3serial Serial String of the USB3 HUB
hceenable Force enable 5
Value : 1 – Force enable
Value : 0 – Default behaviour
swapupstreamdpdm Swaps dp and dm
swapport1dpdm Value : 1 – Swaps D+ and D-
swapport2dpdm Value : 0 – Default behaviour
swapport3dpdm
swapport4dpdm
nrdeviceport4 Configures Port as removable/non-removable
nrdeviceport3 Value : 1 – Port Non-removable
nrdeviceport2 Value : 0 – Port Removable
nrdeviceport1
flexconnect Enables flexconnect. Swaps downstream port1
and upstream
Value : 1 – Enable Flexconnect
Value : 0 – Disable Flexconnect
hubpower Configures hubpower as self-power or bus-
power
Value : 1 – Self-power
Value : 0 – Bus-power
PHYBOOST Configures phy boost Value
PHYBOOSTdownstream 0 – 5% below nominal
port1 1 – Nominal 17.78 mA
PHYBOOSTdownstream 2 – 5% above nominal
port2 3 – 10% above nominal
PHYBOOSTdownstream 4 – 15% above nominal
port3 5 – 20% above nominal
PHYBOOSTdownstream 6 – 25% above nominal
port4 7 – 30% above nominal
SQUELCH Configures Varisense of hub
SQUELCHdownstreamp 0 – 62.5mV below nominal
ort1 1 – 50mV below nominal
SQUELCHdownstreamp 2 – 37.5mV below nominal
ort2 3 – 25mV below nominal
SQUELCHdownstreamp 4 – 12.5mV below nominal
ort3 5 – Nominal 100mV
SQUELCHdownstreamp 6 – 12.5mV above nominal
ort4 7 – 25mV below nominal
downstreamBCsettingp Configures Battery charging of port
ort1 0 – Standard USB port Max-500mA
downstreamBCsettingp 1 – BC 1.2 Compliant Port Max-1.5A
ort2 2 – Most Devices supported mode Max-2A
downstreamBCsettingp
ort3
downstreamBCsettingp
ort4
hce_vid 16-bit value that uniquely identifies the Vendor
ID of the HCE device
hce_pid 16-bit value that the Vendor can assign that
uniquely identifies particular Product for HCE
ID Device
hce_did 16-bit device release number for HCE device in
BCD format
hce_languageid Language id of HCE device
hce_manufacturer Manufacturer string of HCE device
hce_product Product string of HCE device
MICROCHIP CONFIDENTIAL
th
endpoint device
"usb3serial":"456789"
"hceenable":"1"
"swapupstreamdpdm":"1"
"nrdeviceport4":"1"
"flexconnect":"1"
"hubpower":"1"
"PHYBOOSTdownstreamport1":"
1"
"SQUELCHdownstreamport1":"2"
"downstreamBCsettingport1":"1"
"hce_vid":"0x0424"
"hce_pid":"0x2740"
"hce_did":"0x1234"
"hce_languageid":"0x4009"
"hce_manufacturer":"Microchip"
"hce_product":"Controller hub"
