Multiport Multigig Series User Guide

Introduction

Microchip's family of Power over Ethernet (PoE) Midspans, PD-95XX-10GC/AC, inject power over data-carrying
Ethernet cabling. Employing these devices reduces the need for AC outlets, local UPS, and AC/DC adapters near
powered devices (PDs) .
PD-9506-10GC, PD-9512-10GC, and PD-9524-10GC Midspans support 6, 12, and 24 ports respectively, in a
2.5/5/10GBaseT Ethernet network, over TIA/EIA-568 category 5e/6/6A cabling. The PD-95xx-10GC family can
provide up to 60W according to the new IEEE
pairs of wires within a cable (1/2, 3/6, 4/5, and 7/8) to terminal units.
PoE Midspan normally powers devices that are PoE enabled or are equipped to receive PoE. These devices are
called PDs.
PoE Midspans offer the following important features.
Safe and reliable power over an existing Ethernet infrastructure.
Remote management using web control and/or simple network management protocol (SNMP)v3.
High-level of network security.
Safe solution that protects network infrastructure.
Standards compliant: IEEE 802.3bt.
Provides safe power and data over a single RJ-45 cable.
©
2021 Microchip Technology Inc.
and its subsidiaries
®
802.3bt standards. DC power is fed over both spare and data
User Guide
PD-95XX-10GC
DS00004059A-page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PD-95-10GC Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Microchip Technology PD-95-10GC Series

  • Page 1: Introduction

    • High-level of network security. • Safe solution that protects network infrastructure. • Standards compliant: IEEE 802.3bt. • Provides safe power and data over a single RJ-45 cable. User Guide DS00004059A-page 1 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 2: Table Of Contents

    Power Redundancy ........................17 8.2. Power Backup ........................... 17 8.3. Connectors..........................17 8.4. Connecting the Backup and Redundancy Connectors...............18 8.5. Power Backup and Power Redundancy Indications..............19 Contacting Technical Support ......................21 User Guide DS00004059A-page 2 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 3 The Microchip Website..........................24 Product Change Notification Service......................24 Customer Support............................24 Microchip Devices Code Protection Feature....................24 Legal Notice..............................25 Trademarks..............................25 Quality Management System........................26 Worldwide Sales and Service........................27 User Guide DS00004059A-page 3 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 4: Standards And Safety Guidelines

    This ITE device must be connected to PoE (power supply over Ethernet) networks only, without routing to other networks. • The power cord must not be attached to the surface of the building or pass-through walls, ceilings, floors, and similar openings in the building structure. User Guide DS00004059A-page 4 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 5 230V (2P+T) through an isolation transformer with a 1:1 ratio, and with secondary connection point labeled Neutral and connected directly to the ground. U.K. PoE Midspan is covered by General Approval NS/G/12345/J/100003, for indirect connection to a public telecommunications system. User Guide DS00004059A-page 5 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 6: Information En Matière De Sécurité

    être utilisées comme prises de service téléphonique traditionnel. Connecter seulement des connecteurs de données RJ45 à ces prises. Le câblage Ethernet connexe doit être limité à l'intérieur de l'immeuble. User Guide DS00004059A-page 6 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 7: 2.5/5/10Gbase-Tx Ports Definition

    Yellow: The terminal unit (PD) has been identified as PoE Enabled; it is active and receiving power over 2-wire pairs. • Blinking green: The port does not supply power and is inactive. User Guide DS00004059A-page 7 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 8: Connectors

    The Console port is set to 38,400-baud for managed units and 19,200-baud for unmanaged units, 8 data bits, no parity, and 1 stop bit. The figure below displays the pin connections for this connector. User Guide DS00004059A-page 8 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 9 Each data port is configured, as shown in the previous figure, as data Pass-Through ports for all data pins (pins 1, 2, 3, 6, 4, 5, 7, and 8). Ensure that cabling of Category 6A or higher is used. User Guide DS00004059A-page 9 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 10: Poe Midspan Installation

    To install Midspan into a 19-inch rack: Remove the self-adhesive rubber feet from the bottom surface. Install the brackets using three screws each side. Note:  Rack-mounting screws are not provided with the kit. User Guide DS00004059A-page 10 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 11: Installation Factors

    Internal fan operates. • Device runs its Power-On Self-Test (POST), which takes less than 10 seconds. During POST, all ports are disabled and indicators illuminate in the following sequence: User Guide DS00004059A-page 11 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 12 – Power indicator remains lit in green while port indicators are off. Ports are now ready (enabled) for normal operation. If LEDs are not lit, then see Troubleshooting. User Guide DS00004059A-page 12 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 13: Troubleshooting

    Try to reconnect the same PD to a different port on the same Midspan or on another one. If it works, there might be a defect in the port or in the RJ-45 connection. User Guide DS00004059A-page 13 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 14: Specifications

    PD-9512-10GC – 9A PD-9506-10GC – 5A Nominal output voltage 50–57 VDC Maximum output power PD-9524-10GC – 950W PD-9512-10GC – 950W PD-9506-10GC – 450W Maximum output power per port PD-9506/12/24-10GC 60W User Guide DS00004059A-page 14 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 15 PD-95XX-10GC Specifications Table 6-4. Electrical Specifications for PD-PD-9512-10GC and PD-9524-10GC Parameter PD-9512-10GC and PD-9524-10GC DC input rated voltage 53–57 VDC Input DC maximum current User Guide DS00004059A-page 15 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 16: Microchip's Powerview Pro

    Real-time monitoring and configuration with visual status indicators and alarms. • Multi-manager capabilities. • Event and performance data recording. • Runs on a PC platform with Windows GUI. User Guide DS00004059A-page 16 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 17: Power Backup And Power Redundancy Connection

    Power backup and power redundancy control signal connector, COM D-Sub: 15 pins, 3 rows female connector. • DC voltage terminal block connector has two positive (+) terminals and two negative (-) terminals. User Guide DS00004059A-page 17 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 18: Connecting The Backup And Redundancy Connectors

    Verify that the power indicator LED is ON (Green LED). Note:  While connecting a midspan to midspan, connect the earth ground cable between both units Earth Ground connection. Figure 8-2. Connecting Backup and Redundancy Connectors User Guide DS00004059A-page 18 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 19: Power Backup And Power Redundancy Indications

    NMS View-Status window displays a Power Source Status field. The Power Source Status field shows both internal and external power supply statuses (green indicates success and red indicates failure). Figure 8-4. View Status in NMS User Guide DS00004059A-page 19 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 20 Note:  Midspan provides another power failure indication through the Midspan's power indicator LED; whenever the unit's internal power supply fails, the power indicator LED blinks once every second (Green LED). Figure 8-5. PD-95xx-10GC Front Panel LED Indication User Guide DS00004059A-page 20 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 21: Contacting Technical Support

    If you encounter any problems while installing or using this product, contact the Microchip technical support team through the following contact number or website. USA/Canada +1 877 480 2323 www.microchip.com/support User Guide DS00004059A-page 21 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 22: Ordering Information

    Type3 - 60W per port, 2.5/5/10GBaseT, AC Input w/Management, Full power (950W) 6-port PoE Midspan, 6 IEEE 802.3bt PD-9506-10GC/AC Type3 - 60W per port, 2.5/5/10GBaseT, AC Input w/Management, Full power (450W) User Guide DS00004059A-page 22 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 23: Revision History

    PD-95XX-10GC Revision History Revision History Revision Date Description July 2021 Initial Revision User Guide DS00004059A-page 23 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 24: The Microchip Website

    Attempts to break Microchip’s code protection feature may be a violation of the Digital Millennium Copyright Act. If such acts allow unauthorized access to your software or other copyrighted work, you may have a right to sue for relief under that Act. User Guide DS00004059A-page 24 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 25: Legal Notice

    The Adaptec logo, Frequency on Demand, Silicon Storage Technology, and Symmcom are registered trademarks of Microchip Technology Inc. in other countries. GestIC is a registered trademark of Microchip Technology Germany II GmbH & Co. KG, a subsidiary of Microchip Technology Inc., in other countries.
  • Page 26: Quality Management System

    PD-95XX-10GC Quality Management System For information regarding Microchip’s Quality Management Systems, please visit www.microchip.com/quality. User Guide DS00004059A-page 26 © 2021 Microchip Technology Inc. and its subsidiaries...
  • Page 27: Worldwide Sales And Service

    Tel: 631-435-6000 Sweden - Stockholm San Jose, CA Tel: 46-8-5090-4654 Tel: 408-735-9110 UK - Wokingham Tel: 408-436-4270 Tel: 44-118-921-5800 Canada - Toronto Fax: 44-118-921-5820 Tel: 905-695-1980 Fax: 905-695-2078 User Guide DS00004059A-page 27 © 2021 Microchip Technology Inc. and its subsidiaries...
