Protouch2 GUI User Manual

10.4 Change configuration settings

Configuration settings of the hub as desired can be changed from the default or
default+ Load configuration settings as shown below
The SAVE button becomes active as soon as any changes are done

10.5 RESET

If the changes are to be reversed, then the RESET button can be used to reset to
default settings.

10.6 Save the new configuration file

Once the required changes are made, the user can select the File name and click on
the SAVE button
MICROCHIP CONFIDENTIAL Page 33
