Specifications

Refer to the following table for electrical and environmental requirements for the 4100 NIC and media cards.
Electrical specifications
NIC (565-516)
NIC (566-793)
Modem Media Card
(566-279, 566-338)
Dual Fiber Media Card (746-109)
Duplex Fiber Media Card
(566-1197, 566-1198, 566-1199,
566-1200)
Wired Media Card (565-413)
Environmental specifications
Operating temperature
Humidity
Dual fiber-optic specifications (746-109 only)
Fiber type
Interface
Wavelength
Allowed losses
The low power setting is preferred for all 62.5 um fiber links less than 11 dB and 50 um fiber links less than 6.6 dB. JW1 is used to adjust the link
power budget. If you encounter communication problems, ensure the fiber connections comply with ANSI/TIA/EIA 568-C.3 or later industry standard.
Duplex fiber-optic specifications (566-1197, 566-1198, 566-1199, or 566-1200) only
Fiber Type
Interface
Wavelength
Allowed losses / distances
If you encounter communication problems, ensure fiber connections comply with ANSI/TIA/EIA 568-C.3 or later industry standard.
Initial acceptance test requirements for fiber optic installations are as follows:
• An initial acceptance test of each fiber link shall be performed as stated in NFPA 72. A fiber link is defined as all fiber segments, including patch
cords, which create a fiber path from one fiber media board to another. The fiber lines shall be tested using an OTDR. The OTDR will measure
the attenuation of the fiber as well as indicate the presence and location of connectors and any defects in the link. The fiber infrastructure
shall be accepted for use only after it has been determined it meets or exceeds industry standard ANSI TIA/EIA 568-C.3 or later (Electronic
Industries Alliance/Telecommunications Industry Association, Optical Fiber Cabling Components Standard).
• OTDR Launch and Receive cables of appropriate length shall be used. If a single cable is used, each link shall be tested in both directions.
• Multi-mode fiber links shall be measured at 850 nm and 1300 nm.
• Single-mode fiber links shall be measured at 1310 nm and 1550 nm.
page 9
Table 1: Electrical and environmental specifications
Startup, no media cards: 8 VDC at 110 mA Nominal, no media cards: 20 to 32 VDC at 0 mA
Nominal, no media cards: 20 to 32 VDC at 46 mA
5 VDC at 180 mA max.
Using 24 V power supply: 20 VDC at 140 mA max.
Using 5 V power supply: 5 VDC at 130 mA max.
Using 24 V power supply: 24 VDC at 55 mA max.
Using 5 V power supply: 5 VDC at 220 mA max.
55 mA max at 24 VDC
Output Voltage: 4.75 V min to 5.25 V max.
32 ° to 120 °F (0 ° to 49 °C)
10% to 93% relative humidity at 90 °F (32 °C)
Multi-mode
ST Connector
850nm
50/125 um fiber
High setting: 17 dB
Medium setting: 11.6 dB
Low setting: 6.6 dB
62.5 um fiber
High setting: 20.4 dB
Medium setting: 16dB
Low setting: 11 dB
Table 2: Duplex fiber-optic specifications
Multi-mode
Single-mode
SC Connector
Right Media (SM and MM)
Left Media (SM and MM)
Multi-mode
Single-mode
Right: 566-1199, Left: 566-1200
Right: 566-1197, Left: 566-1198
1310 nm transmit; 1550 nm receive
1550 nm transmit; 1310 nm receive
50/125 um fiber
62.5/125 um fiber
9/125 um fiber
18 dB/5 km
18 dB/5 km
22 dB/25 km
