This publication describes the installation procedure for the following 4100-Series System Power
Introduction
Supplies (SPS) and Remote Power Supplies (RPS):
These products are compatible with 4100U and 4100ES Fire Alarm Control Panels
(FACP).
IMPORTANT:
In this Publication
This publication discusses the following topics:
City and relay connections can be made from the SPS (the RPS supports relay connections only).
Related
Refer to the City and Relay Card Installation Instructions (574-839) to install a relay card to the
Documentation
SPS, or a city card to the SPS or RPS.
To find out more about the CPU bay version of the SPS, which operates in the same way as the
expansion bay version of the SPS but mounts differently, refer to the 4100ES Fire Alarm System
Installation Guide (574-848).
For information on Expansion Power Supplies (XPS), refer to XPS and XNAC Installation
Instructions (574-772).
2005, 2008, 2009, 2011 SimplexGrinnell LP. All rights reserved.
Specifications and other information shown were current as of publication and are subject to change without notice.
Simplex and the Simplex logo are trademarks of Tyco International Ltd. and its affiliates and are used under license.
4100-5111/5112 SPS (120 VAC) (mounts to expansion bays only)
4100-5125/5126 RPS (120 VAC)
4100-5113 SPS (220/230/240 VAC) (mounts to expansion bays only)
4100-5127 RPS (220/230/240 VAC)
The SPS described in this document are not physically the same as the SPS
used in the CPU bay.
Verify FACP System Programmer, Executive, and Slave Software compatibility
when installing, or replacing system components. Refer to the Technical
Support Information and Downloads website for compatibility information.
firealarmresources.com
Installation Instructions
Topic
SPS/RPS
See Page #
2
3
7
8
10
12
23
26
29
31
579-246
Rev. K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4100 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Simplex 4100 Series

Summary of Contents for Simplex 4100 Series

  • Page 1: Table Of Contents

    579-246 Specifications and other information shown were current as of publication and are subject to change without notice. Rev. K Simplex and the Simplex logo are trademarks of Tyco International Ltd. and its affiliates and are used under license. firealarmresources.com...

  • Page 2: Cautions And Warnings

    DO NOT INSTALL ANY SIMPLEX® PRODUCT THAT APPEARS DAMAGED- Upon unpacking your Simplex product, inspect the contents of the carton for shipping damage. If damage is apparent, immediately file a claim with the carrier and notify an authorized Simplex product supplier.

  • Page 3: Introduction To The Sps And Rps

    Introduction to the SPS and RPS Overview The System Power Supply (SPS) and Remote Power Supply (RPS) are both intended to be placed in remote cabinets that require a 24 VDC signal power, as well as battery charging capabilities. The SPS and RPS receive battery and AC power from the Power Distribution Module (PDM).
  • Page 4 Introduction to the SPS and RPS, Continued Overview The figure below details the SPS. The only difference in physical appearance between the SPS and the RPS is that the SPS contains IDNet screw terminals. IDNet Terminal Block (TB1; SPS only) NAC Terminal Block (TB2) Power/Comm to P1 of PDI (P6)
  • Page 5 Introduction to the SPS and RPS, Continued Input/Output/Battery The table below summarizes the specifications for the SPS and RPS. Specifications Table 1. Input and Output Specifications AC Input Specifications 4100-5111/5112 SPS 4 A Maximum 4100-5125/5126 RPS 120 VAC @ 60 Hz, nominal 4100-5113 SPS 2 A Maximum 4100-5127 RPS...
  • Page 6 Introduction to the SPS and RPS, Continued SPS Current The table below summarizes battery standby capabilities for the SPS. Voltage assumed is 24 V, Consumption which is the rated battery voltage for lead-acid type batteries. Table 2. SPS Current Specifications Standby Conditions Current ...

  • Page 7: Mounting

    Mounting Overview The SPS and RPS mount onto the right side of an expansion box, and connect to the PDI. Use this section to mount the SPS or RPS assembly to the box. Mounting Use the following directions and the figure below to mount the SPS or RPS to an expansion cabinet. 1.

  • Page 8: Configuring The Sps And Rps

    Configuring the SPS and RPS Overview The SPS and RPS have jumper ports (see Figure 1) for the IDNet shield connection, Earth ground monitoring, and for city or relay module trouble activation. The SPS and RPS also require an address setting via DIP switch SW1. This section describes each setting. Jumper Settings Earth Fault Monitor jumper.
  • Page 9 Configuring the SPS and RPS, Continued Setting the Address Table 4. Card Addresses Address SW 1-2 SW 1-3 SW 1-4 SW 1-5 SW 1-6 SW 1-7 SW 1-8 Address SW 1-2 SW 1-3 SW 1-4 SW 1-5 SW 1-6 SW 1-7 SW 1-8 firealarmresources.com...

  • Page 10: Internal Wiring

    Internal Wiring Overview The SPS and RPS get their power from the Power Distribution Module (PDM). The PDM takes power directly from a dedicated AC line and the two backup batteries, and distributes power to each bay in the cabinet. Power Distribution The power distribution module (PDM) connects to the SPS, RPS, or XPS in each bay.
  • Page 11 Internal Wiring, Continued Power Distribution 4. Connect the PDM to the SPS or RPS using Harness 734-012 (734-013 for 220/230/240VAC Module Connections versions).  Feed Red and Black wires through the side rail to the front of the SPS or RPS to prevent wire damage when the front panel is inserted.

  • Page 12: Nac Field Wiring

    NAC Field Wiring Overview The SPS and RPS provide three outputs for reverse-polarity notification appliance circuits. This section describes basic NAC wiring from the SPS and RPS to 4100-compatible appliances. NAC Wiring Styles The SPS and RPS supports both Class A and Class B NAC wiring. Class A wiring allows appliances to communicate with the SPS or RPS even in the event of an open circuit somewhere in the loop.
  • Page 13 NAC Field Wiring, Continued Class B NAC The table below lists the maximum distances from the SPS or RPS to the last appliance in a Wiring Table Class B configuration, depending on wire gauge and current. Use this table to calculate wire distances for your application if you are using Class B wiring.
  • Page 14 NAC Field Wiring, Continued Guidelines  All wiring is 18 AWG (0.8231 mm ) (minimum) to 12 AWG (3.309 mm ) (maximum).  All wiring is supervised and power-limited.  The maximum alarm current is 3 A per circuit. The supervisory current is 2.03 mA at 24 VDC.
  • Page 15 NAC Field Wiring, Continued  Guidelines Compatible appliances for NACs are shown in Table 7: Table 7. Compatible Appliances and Accessories (for Special Application NACs) Description Description Description 4904-9168 V/O 15CD RED FREE-RUN TNA 4906-9102 V/O 15/30/75/110cd C/M RED TNA 4903-9253 A/V 24VDC 30CD RED HOR F/S 4904-9171...
  • Page 16 NAC Field Wiring, Continued Table 8. COOPER WHEELOCK APPLIANCES (Compatible with 4100U/4100ES SPS/RPS Wheelock Protocol for Special Applications) SYNCHRONIZING HORN STROBES AS-241575W AS Series Horn Strobe. 24V, 15/75Cd, Wall Mount AS-24MCW AS Series Horn Strobe. 24V, Multi-Cd, Wall Mount AS-24MCC AS Series Horn Strobe.
  • Page 17 NAC Field Wiring, Continued Table 8. COOPER WHEELOCK APPLIANCES (Compatible with 4100U/4100ES SPS/RPS Wheelock Protocol for Special Applications) RSSWPA-2475W RSS Series WP Strobe. 24V, Wall Mount. Amber RSSWPA-24MCCH, RSSWPB-24MCCH, RSSWPG-24MCCH, RSSWPR-24MCCH RSS Series WP Strobe. 24V, Multi-High-Cd, Ceiling Mount.Amber/Blue/Green/Red. RSSWP-2475W, RSSWP-2475C RSS Series WP Strobe.
  • Page 18 NAC Field Wiring, Continued Table 8. COOPER WHEELOCK APPLIANCES (Compatible with 4100U/4100ES SPS/RPS Wheelock Protocol for Special Applications) CH90-24MCCH CH90 Series Chime Strobe. 24V, Multi-High-Cd, Ceiling Mount E50-241575W E50 Series Speaker Strobe. 24V, 15/75Cd, Wall Mount E50-24MCW E50 Series Speaker Strobe. 24V, Multi-Cd, Wall Mount E50-24MCWH E50 Series Speaker Strobe.
  • Page 19 NAC Field Wiring, Continued Table 8. COOPER WHEELOCK APPLIANCES (Compatible with 4100U/4100ES SPS/RPS Wheelock Protocol for Special Applications) CODED AUDIBLE APPLIANCES AMT-12/24, AMT-12/24-NYC AMT Series, Multi-tone horn, 12/24V, Wall or Ceiling Mount CH70, CH90 CH70/CH90 Series chime, 24V, Wall or Ceiling Mount CSX10-24-DC, CSXG10-24-DC CSX SeriesBell, 24V, Wall Mount MT-12/24, MT4-12/24...
  • Page 20 NAC Field Wiring, Continued Guidelines The Notification Appliance Circuits on the SPS or RPS are rated for Special Application and for regulated 24Vdc operation per UL864, 9th Edition. When used with the Notification Appliances listed in Table 7 or Table 8, each NAC is rated for 3A, and total SPS capacity is rated at 9A.
  • Page 21 NAC Field Wiring, Continued Class A NAC Wiring To connect the RPS or SPS to reverse-polarity, non-addressable notification appliances using Class A wiring, read the following instructions and refer to the figure below. 1. Route wire (between 12 [3.309 mm ] and 18 AWG [0.8231 mm ]) from the “B+”...
  • Page 22 NAC Field Wiring, Continued Class B NAC Wiring To connect the SPS to appliances using Class B wiring, read the following instructions and refer to the figure below. 1. Route wire (between 12 [3.309 mm ] and 18 AWG [0.8231 mm ]) from the “B+”...

  • Page 23: Idnet Field Wiring (Sps Only)

    IDNet Field Wiring (SPS only) Overview Much of the field wiring on any system is routed from the SPS to remote devices and appliances. Which inputs on the SPS are used depends on the type of communications being used. This section describes how the SPS connects to IDNet initiating devices.
  • Page 24 IDNet Field Wiring (SPS only), Continued Class A Wiring To connect the SPS to IDNet appliances using Class A wiring, read the following instructions. 1. Route wire (between 12 [3.309 mm ] and 18 AWG [0.8231 mm ]) from the B+, B-, and SHIELD outputs on TB1 of the SPS to the appropriate inputs on a peripheral IDNet appliance.
  • Page 25 IDNet Field Wiring (SPS only), Continued Class B Wiring To connect the SPS to IDNet appliances using Class B wiring, read the following instructions. 1. On TB1, jumper B+ to A+, and jumper B- to A-. If the jumper is absent, a Class A Trouble is indicated on LED 5.

  • Page 26: Auxiliary Power Wiring

    Auxiliary Power Wiring Guidelines The SPS and RPS can connect to auxiliary power appliances via the dedicated auxiliary power tap (TB3). If more power is needed, any of the three NAC outputs can be used for auxiliary power.  All wiring must be between 18 AWG (0.8231 mm ) and 12 AWG (3.309 mm ...
  • Page 27 Auxiliary Power Wiring, Continued  Guidelines Auxiliary power only: In order to connect a circuit using power-limited wiring, the devices being powered must all be addressable, or a UL-Listed EOL relay must be used to supervise the circuit. Refer to the figure below for wiring directions for the EOL relay. TO AUX POWER Note: The 2098-9739 Relay is used as...
  • Page 28 Auxiliary Power Wiring, Continued Wiring The figure below shows how the SPS or RPS is wired for auxiliary power at any given terminal. Note: To program relay contacts, refer to the ES Panel Programmer’s Manual (574-849). AUXILIARY AUXILIARY AUXILIARY POWER POWER POWER Ferrite bead...

  • Page 29: Auxiliary Relay Wiring

    Auxiliary Relay Wiring Overview The SPS includes one on-board, programmable relay. Guidelines  All wiring must be between 18 AWG (0.8231 mm ) and 12 AWG (3.309 mm  When power through auxiliary contacts is provided by the SPS or RPS, wiring is power-limited.
  • Page 30 Auxiliary Relay Wiring, Continued Wiring The figure below shows SPS/RPS auxiliary relay wiring. Note: To program relay contacts, refer to the ES Panel Programmer’s Manual (574-849). AUXILIARY AUXILIARY AUXILIARY POWER POWER POWER B- A+ A- B+ B- A+ A- B+ B- A+ A- SPS or RPS Dedicated auxiliary power screw terminal...

  • Page 31: Troubleshooting

    Troubleshooting Overview This section describes the messages that may appear on the 4100 display when using the SPS or RPS. Trouble messages appear on the left as titles, and possible causes are listed to the right in the text. AC Power Loss Indicates AC power to the system is absent or is lower than 85% of nominal (102 VAC for a 120 VAC system).
  • Page 32 579-246 Rev. K firealarmresources.com...
