Introduction
This publication describes the installation procedure for the following:
•
4100/4120-0155 Serial Digital Alarm Communications Transmitter (DACT) (non-4100U/4100ES)
•
4100-6052 DACT (4100U/4100ES)
_________________________________________________________________________________
•
Related
Field Wiring Diagram for 4100 Power Limited (841-731) or,
Documentation
•
Field Wiring Diagram for 4100 Non Power Limited (841-995)
•
4100ES Fire Alarm System Installation Guide (574-848)
•
T-Link TL250/TL300 Network Internet Alarm Communicator #29034631
•
C900V2 Installation Guide Dialer Capture Ethernet Module # F01U003472-02
_________________________________________________________________________________
Content
This publication covers the following topics:
Cautions and Warnings
Introduction
Power-Limited Wiring Guidelines
Connecting to the Phone Lines (not required when TL300 is used)
Configuring the DACT
Data and Power Wiring
Mounting
Programming
Testing
Compatibility
© 2005-2011 SimplexGrinnell LP. All rights reserved.
Specifications and other information shown were current as of publication and are subject to change without notice.
Simplex and the Simplex logo are trademarks of Tyco International Ltd. and its affiliates and are used under license.
4100/4120-Series Digital Alarm
Communications Transmitters
Topic
firealarmresources.com
Installation Instructions
Page
2
3
6
7
8
10
13
15
16
17
574-836
Rev. N

Advertisement

loading
Need help?

Need help?

Do you have a question about the 4100 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Simplex 4100 Series

Summary of Contents for Simplex 4100 Series

  • Page 1 574-836 Specifications and other information shown were current as of publication and are subject to change without notice. Rev. N Simplex and the Simplex logo are trademarks of Tyco International Ltd. and its affiliates and are used under license. firealarmresources.com...

  • Page 2: Cautions And Warnings

    DO NOT INSTALL ANY SIMPLEX PRODUCT THAT APPEARS DAMAGED your Simplex product, inspect the contents of the carton for shipping damage. If damage is appar- ent, immediately file a claim with the carrier and notify an authorized Simplex product supplier.
  • Page 3 Introduction Overview Digital Alarm Communications Transmitter’s (DACT) are option cards that mount within 4100 Fire Alarm Control Panels (FACP). The 4100/4120-0155 Serial DACT, available for the 4100 (non-4100U/4100ES) only, can be programmed to notify the central station when specified events occur, or to report changes to a specific point’s status.
  • Page 4 Introduction (continued) C900V2 Ethernet The DACT receives system status messages from the 4100U/4100ES using the codes listed on Transmission (UL page 17. It then communicates the information over an Ethernet connection to a DACR at the only) central station. The telephone connections on the DACT are connected together; R1 (TB1-2) to R2 (TB2-2) and T1 (TB1-3) to T2 (TB2-3).
  • Page 5 Introduction (continued) LEDs Refer to Table 1 for DACT LED indicators. Table 1. LED Indications Possible State Not Illuminated. The system is not receiving DC power, or the power-up self-test failed. Power (LED 1) On Steady. The DACT is receiving DC power and is operational. Green LED Flashing.
  • Page 6 Power-Limited Wiring Guidelines • Power-limited Non-power limited field wiring (AC power, batteries, City connection) must be installed and routed in the shaded areas shown in Figure 2. Wiring Guidelines • Power-limited field wiring must be installed and routed in the non-shaded areas shown in Figure 2, with the exception of City wiring.
  • Page 7 The connection to the RJ-31X jacks must be made via the modular jack in installations where the 2080-9047 DACT will share the telephone line with premises phones or other equipment. Use two Simplex Harness to the harnesses for this connection - 2080-9047 (14 feet).
  • Page 8 Configuring the DACT Overview Configuring the DACT consists of: • Setting the correct communication mode • Specifying whether the DACT is in Test mode • Specifying whether the DACT should be ready to download new programming data • Setting the device address This section covers all of these settings.
  • Page 9 Configuring the DACT (Continued) Setting the Table 3. DACT card switch settings address firealarmresources.com...
  • Page 10 Data and Power Wiring Wiring Guidelines Review the following guidelines before wiring P1 and P4 of the DACT. • If U.T. motherboard 565-274 or 565-213 is wired to the DACT, jumper P4 on the motherboard must be at position 13. •...
  • Page 11 Data and Power Wiring (Continued) Wiring the DACT Wire the DACT to the TL300 in accordance with Figure 6 and Figure 7. to the TL300 DSC FC5003 Cabinet T-Link TL300 Network #18 - #26 awg PGM2 PGM1 Earth EOLR for IDC See note 3 #18 - #22 awg #18 - #22 awg...
  • Page 12 Data and Power Wiring (Continued) Wiring the DACT to the C900V2 DACT (UL only) Figure 7 Notes: 1. A Bosch C900V2 in a Bosch AE2 enclosure must be mounted within 20 feet of the FACP and be in the same room as it. The wiring to the FACP must be enclosed in the conduit or be equivalently protected...
  • Page 13 Mounting Overview Both assemblies are designed for different systems. • The 4100/4120-0155 Serial DACT mounts into a non-4100U/4100ES systems (with 2975- 91xx Back Boxes). • The 4100-6052 DACT mounts into a 4100U/4100ES systems (with 2975-94xx Back Boxes). This section describes how to mount the cards into both types of bays. Mounting Serial Use the instructions and figure below to mount a 4100/4120-0155 Serial DACT bracket into a DACT 4100/4120-...
  • Page 14 Mounting (Continued) • Mounting DACT The 4100-6052 DACT can only be installed in the CPU bay. 4100-6052 • The DACT must be the leftmost assembly in the CPU bay. • See Figure 9. 1. Disconnect AC power at the source. Disconnect the + (red) wire from the battery. 2.
  • Page 15 Programming 4100/4120 The DACT must be selected in the Programmer. Refer to Serial DACT Installation and Program- Programming ming Instructions (574-090) for specific programming requirements. 4100U/4100ES The correct DACT card must be selected in the 4100U/ES Panel Programmer. Refer to the Programming ES Panel Programmer’s Manual (574-849).
  • Page 16 Testing Testing When the DACT is connected to the system, its operations should be tested with the manual TEST switch (SW1). The manual test ensures that: • The phone line is working. • The DACT has been programmed with a correct phone number. •...
  • Page 17 Compatibility Compatibility Refer to Table 4 for compatibility information. Table 4. Compatibility information Comm. Osborne/ ADEMCO Silent BOSCH SUR-GARD Format MLR2-DG Hoffman Knight CP220FB RADIONICS (Notes 2, 6) 9000 (Notes 5, 6) 6500/6600 (Note 7 Quickalert Model II (Notes 6, 8 3/1 Standard (Note 3) 1800/2300 Hz...
