IMPORTANT:
Do not apply AC power or batteries until the system
is completely wired and ready for testing.
120 V A C , 5 0/60 H z
P rim ary P ow er S ourc e
Hot N eutral
1
2
3
4
G C 1 2550
12 V D C
55-A H
B a ttery
NR45-24
Figure 34: Remote Battery Charger Connection
Hardware Installation—IFC-200 Hardware Installation Procedures
Cut JP2
to disable
internal
charger.
G C 1 2550
12 V D C
55-A H
B a ttery
JP2
ABC
DE F
1
3
2
GHI
J KL
M NO
4
5
6
P RS
T UV
WX Y
7
8
9
.
Q Z
*
#
0
D ET
MOD
ENTER
J3
-
+
Cut terminals from IFC-200
battery cable connected to J3.
Use wire nuts.
FIG2-25
41
