Johnson Controls Metasys IFC-200 Installation Procedures Manual page 33

IF C -2 0 0
TB1
+
-
+
24V(+) TB1-5 -
24V(-) TB 1-6
+
-
TB2
B+
B-
B+
B-
B+
B-
B+
B-
TB3
NO
C
NO
NC
C
NO
NC
C
TB4
TX
CAUTION!
REF
wiring under any terminals.
RX
Break wire run to maintain
REF
supervision.
TB5
OUT
OUT
IN
IN
TB6
A
B
B+
SLC(+ ) T B6-3
A+
SLC(-) T B6-5
B-
A-
Figure 25: NFPA Style Z Indicating Appliance Circuit
Hardware Installation—IFC-200 Hardware Installation Procedures
UL Listed 24 VDC Indicating Appliances
System Sensor MA-12/240 Electronic Sounder
System Sensor SS-24 Strobe
System Sensor MA/SS-240 Electronic Sounder/Strobe
Wheelock 7002T-24 Horn with Strobe
Wheelock Series WM Strobes
Wheelock Series EH Electronic Strobe Horns
Wheelock Series AES Multi-Tone Signals
Wheelock Series MIZ Mini-Horns
To Next Device
on SLC
M510CJ
Rated for
1 amp for Inductive
Loads, 2 amps
for Resistive Loads. MAX
SLC
Out
1
2
3
4
Do not loop
2 4 V D C In dica ting A pp lian ce s
9
8
7
6
5
A77-716B
Power Supervision
Relay
FIG2-18
33
