Johnson Controls Metasys IFC-200 Installation Procedures Manual page 13

1. Enter Setup Mode on the CRT-1 by pressing
simultaneously.
2. Notice that the SET 0 setup menu displays on the bottom line of the
CRT-1 screen. In setup mode, there are six setup menus
(numbered 0-5). Each setup menu is divided into parameter blocks
containing user-selectable values.
3. Select the operational parameters for the CRT-1 as shown below.
CRT-1 (newer model with pastel-colored function keys only)
SET 0 | FDX | P PAGE | S PAGE | PROT OFF | COPY |
(MON) OFF | GRAPH OFF | HI OFF | RS:2400
SET 1 | KEYS:
MRG BL OFF | EOM: NULL | AUX 2400
SET 2| WRAP OFF | LF OFF | SCROLL ON | KB ON |
DISPLAY PE OFF | STD VID | X-ON ONLY
Note: KB OFF for a CRT-1 without a keyboard.
SET 3 | DATA BIT 7 | BIT8 0 | PARITY ON | PARITY
BIT EVEN | STOP BIT 1 | EMULATION T101+
SET 4 | CURSOR UL | CURSOR BLINK | HERE IS:~~|
TIME OFF | FREQ 60
Note: To change the "HERE IS" parameter, press the Enter key on
the number pad. Pressing Enter also saves changes.
SET 5| KB TYPE:US | STATUS LINE OFF | AUX/KB:KB |
AUTO PG OFF | AUX:X-ON ONLY | RS232
4. To advance through the blocks of a given setup menu, press
or
5. To advance through the setup lines, press
or
6. To change a parameter block press
until the desired value is displayed, then press any arrow key to move
the cursor from the current parameter block.
7. To save Setup mode parameters entered, press
the same time. To terminate the Setup mode, press
8. All the values displayed in the parameter blocks on the screen are
stored permanently, even if power to the CRT-1 is removed.
Note: If any mistakes are made during the setup process, simply repeat
this procedure.
Hardware Installation—IFC-200 Hardware Installation Procedures
| REPT OFF | CLICK ON | EDIT DUPE |
Setup
SHIFT
Hold
and
SPACE
SHIFT
S
and
Setup
Hold
.
at
13
