Monitor Modules

Control Modules

Intelligent
Detectors

Device Capacity

Table 3: Communications SLC Performance
Fault Condition
Single Single
Open on Ground
Loop on Loop
Style 4 (Two Wire) SLC Operation (Meets NFPA 72 Style 4 Requirements)
1
Trouble Alarm
Capability
2
Trouble
Style 6 (Four Wire) SLC Operation (Meets NFPA 72 Style 6 Requirements)
Alarm Alarm
Capability Capability
Trouble Trouble
Style 7 (Four Wire) SLC Operation
Alarm Alarm
Capability Capability
Trouble Trouble
Notes: 1 Trouble indicates a trouble signal will be generated at the control panel during the abnormal condition.
2 Alarm Capability indicates an alarm signal can be transmitted to the control panel during the abnormal condition.
3 Loop operation meeting Style 7 requirements isolates entire physical "zones" on the communications loop from
faults that occur within other areas of the loop.
M500MJ and M501MJ addressable monitor modules allow the IFC-200 to
monitor entire circuits of conventional normally open contacts, alarm
initiating devices, manual pull stations, normally open alarm contacts of 4-
wire smoke detectors, heat detectors, waterflow, and supervisory devices
(Figures 18 and 19). The M502MJ Addressable Monitor Module can
directly power 24 VDC 2-wire UL Listed smoke detectors. Point
annunciation of manual pull stations is provided with the BGX-101L
addressable pull station (Figures 10 and 11).
Through M510CJ addressable control modules, the IFC-200 can
selectively activate indicating appliance circuits or Form-C output relays
(Figures 22 through 25).
Through the SLC, the IFC-200 communicates with intelligent ionization,
photoelectric, and thermal detectors (Figure 27).
The capacity of each IFC-200 is up to 99 intelligent detectors, and an
additional combination of up to 99 addressable pull stations, control
modules, and monitor modules. In addition, the IFC-200 supports four
indicating appliance circuits.
Note: Refer to the Supply Calculations section of this document and the
installation drawings supplied with each device for rating and
specification information.
Loop
Shorted Shorted and
Loop Opened
Trouble Trouble
Trouble Trouble
3
(Meets NFPA 72 Style 7 Requirements)
Alarm Trouble
Capability
Trouble
Hardware Installation—IFC-200 Hardware Installation Procedures
Loop Loop
Shorted and Opened and
Grounded Grounded
Trouble Trouble
Trouble Alarm
Capability
Trouble
Alarm Alarm
Capability Capability
Trouble Trouble
Communications
Loss
Trouble
Trouble
Trouble
