HDMI KVM EXTENDER
OVER NETWORK CABLE
INTRODUCTION
This HDMI Extender includes a transmitter unit and a receiver unit, allows the HDMI signal to
be transmitted up to 70 meters at 1080p resolution using a Cat6/6A/7 network cable. It adopts
a point-to-point connection configuration, supports KVM remote control and management
and 3.5 mm stereo audio output. It is perfect for outdoor advertising, monitor system, home
entertainment, conference, etc.
FEATURES
1. Zero latency
2. Support up to 1080p@60Hz resolution
3. Supports Cat6/6A/7 network cables, the transmission distance is up to 70 meters
4. Support KVM remote control and management
5. Support 1080p HDR10, YUV4:4:4
6. Support EDID passthrough
7. Transmitter supports HDMI loop-out
8. Receiver supports 3.5 mm stereo audio output
9. Audio formats supported: PCM, LPCM, DTS HD, DTS Audio
10. Automatically adjusts parameters to match different network cables and achieve the best
display performance
11. Lightning Protection, Surge Protection, ESD Protection

PACKAGE CONTENTS

• 1x Transmitter Unit
• 1x Receiver Unit
• 2x DC5V/1A
• 1x User Manual
• 1x USB Cable

INSTALLATION REQUIREMENTS

1. HDMI source device (compute graphics card, DVD, PS4, HD monitoring equipment etc.)
2. HDMI display device like SDTV, HDTV, projector with HDMI port
3. UTP/STP CAT6/6A/7 cable. Follow standard IEEE-568B. It is recommended to select a
network cable with less loss and crosstalk.
