Installation
Environmental Requirements
Environmental Requirements
Set up the E5061B where the following environmental requirements are met.
Operating Environments
Ensure that the operating environment meets the following requirements.
Temperature
Temperature range at
the error-correction
Humidity
Altitude
Vibration
Above environmental requirements are NOT for the specifications and
measurement accuracy of the analyzer, but for the operating environment
of the analyzer.
Ventilation Requirement
To ensure safety requirements, the specifications and measurement accuracy
of the analyzer, you must keep the environmental temperature within the
specified range by providing appropriate cooling clearance around the analyzer
or, for the rack mount type, by forcefully air-cooling inside the rack housing.
For more information on environmental temperature to satisfy the
specifications and measurement accuracy of the analyzer, see the specification
in the E5061B Online Help.
When the environmental temperature around the analyzer is kept within the
temperature range of the operating environment specification (See Section
"Operating Environments" on page
requirements of the safety standard. Furthermore, under that temperature
requirement, the analyzer still conforms to the requirements of the safety
standard even when placing the analyzer with cooling clearance as follows:
Back
Sides
Keysight E5061B Network Analyzer
5°C to 40°C
23°C ± 5°C (<1°C deviation from the temperature when
performing the error-correction)
20% to 80% at web bulb temperature <+29°C
(non-condensation)
0 to 2,000m (0 to 6,561 feet)
0.21G maximum, 5Hz to 500Hz
Requirements
≤ 180mm
≤ 60mm (both right and left)
17), the analyzer conforms to the
17
