S E R V I C E
E5071C - ENA Series Network Analyzer, 9 kHz to 20 GHz
Serial Numbers: MY46100000-MY46199999, MY46200000-MY46299999, MY46300000-
MY46399999, SG46100000-SG46199999, SG46200000-SG46299999, SG46300000-SG46399999
E5071C LCD Touch Panel Display Assembly Replacement Part Change
Parts Required:
P/N
For E5071C Opt 240 to 485 – (Up to 8.5 GHz range)
For E5071C Opt 2D5 to 4K5 – (Up to 20 GHz range)
ADMINISTRATIVE INFORMATION
SERVICE NOTE CLASSIFICATION:
[[]] Calibration Required
X Calibration NOT Required
ADDITIONAL INFORMATION: This service note communicates the support parts strategy for E5071C LCD Touch Panel
display assembly.
© Keysight Technologies 2014
Printed in U.S.A
Description
INFORMATION ONLY
E5071C-31A
N O T E
Qty.
PRODUCT LINE: WN
AUTHOR: LS
Calibration NOT Required
Supersedes:
E5071C-31
October 24, 2014
Rev. 1
Page 1 of 22
