- Page 1 Tiger G2 End user instructions TG-R4-1, TG-R4-3, TG-R4-5 Receivers TG-R4-6, TG-R4-8, TG-R4-10 TG-R4-26, TG-R4-28 TG-R4-36, TG-R4-38, TG-R4-40 TG-R4-41, TG-R4-43, TG-R4-45 ED-TG2-RX101-B01-EN Language: English (original)
-
Page 2: Table Of Contents
CONTENTS CHAPTER 1: CUSTOMER INFORMATION Thank you for purchasing a Tele Radio AB product About Tiger TG2 systems About this document Warnings & restrictions CHAPTER 2: PRODUCT DESCRIPTION Base board Expansion boards Technical data Current consumption Fatal error indications and error code messages Relay functionality Mechanical installation CHAPTER 3: GUARANTEE, SERVICE, REPAIRS AND MAINTENANCE... -
Page 3: Chapter 1: Customer Information
Read all instructions and warnings carefully before mounting, installing and configuring the products. These instructions have been published by Tele Radio AB and are not subject to any guarantee. The instructions may be withdrawn or revised by Tele Radio AB at any time and without further notice. -
Page 4: About Tiger Tg2 Systems
Tiger G2 radio remote controls are easy to operate. ABOUT THIS DOCUMENT Every care has been taken in the preparation of this manual. Please inform Tele Radio AB of any inaccuracies or omissions. These End user instructions cover general safety issues, main technical specifications, standard installation, operating instructions, general troubleshooting, battery information and regulatory information. - Page 5 Operation This radio system should not be used in areas where there is a risk of explosion. Only qualified personnel should be permitted to access the transmitter and operate the equipment. Always follow operating and maintenance instructions as well as all applicable safety procedures and requirements.
-
Page 6: Chapter 2: Product Description
Make sure the power supply is switched off before opening the receiver. BASE BOARD NOTE! This base board is fitted in the following receiver models: TG-R4-1, TG-R4-3, TG-R4-5 TG-R4-6, TG-R4-8, TG-R4-10 TG-R4-26, TG-R4-28 TG-R4-36, TG-R4-38, TG-R4-40 TG-R4-41, TG-R4-43, TG-R4-45 ... - Page 7 LED indicators on the base board NOTE! These LEDs are found in the following receiver models: TG-R4-1, TG-R4-3, TG-R4-5, TG-R4-26, TG-R4-28, TG-R41, TG-R43, TG-R45 The base board has 8 LEDs for relay status indication. The LED lights when the corresponding relay on the base board is activated.
-
Page 8: Expansion Boards
EXPANSION BOARDS Relay expansion board NOTE! This expansion board is fitted in the following receiver models: TG-R4-6, TG-R4-8, TG-R4-10 1. Terminal block for digital inputs 5. Terminal block for function relays R10–R19 2. LED indicators for relays R10–R19 (red) 6. - Page 9 LED indicators for the base board function relays (LEDs 1–9) NOTE! These LEDs are found in the following receiver models: TG-R4-6, TG-R4-8, TG-R4-10, TG-R4-36, TG-R4-38, TG-R4-40 On the expansion board, LEDs 1–9 provide feedback information about the stop relays (SR1–2) and the function relays (R1–R7) on the base board, hidden behind the expansion board.
- Page 10 CANopen status and error LEDs CANopen run status Colour Flickering together Single flash Blinking with Error LED Green Operational state Stopped state Pre-operational state CANopen communication Description states Operational State for process data transmission. LSS services in progress Stopped Except for node guarding or heartbeat messages, a node cannot transmit or receive any other messages in this state.
- Page 11 Analogue expansion board NOTE! This expansion board is fitted in the following receiver models: TG-R4-36, TG-R4-38, TG-R4-40 1. Terminal block for analogue outputs 9. Function relays 22–25 (change-over) 2. LED indicator for the communication with 10. Terminal block for function relays the base board (green) R22–R25 3.
-
Page 12: Technical Data
TECHNICAL DATA TG-R4-1 TG-R4-6 TG-R4-36 TG-R4-26 TG-R4-41 TG-R4-3 TG-R4-8 TG-R4-38 TG-R4-28 TG-R4-43 TG-R4-5 TG-R4-10 TG-R4-40 TG-R4-45 Input power 12–24 V AC/DC, 48–230 V AC, 50–60 Hz, max. 2 A Number of stop relays 2 (potential free*, 16 A, 250 V AC) Number of relays (potential free*, 10 A, 250 V AC) -
Page 13: Current Consumption
TG-R4-38 TG-R4-45 TG-R4-41 TG-R4-43 power Antenna 1 BNC connector for 1 RP-SMA connector for external antenna external antenna CURRENT CONSUMPTION Input TG-R4-1, TG-R4-3, TG-R4-5, TG-R4-6, TG-R4-8, TG-R4-36, TG-R4-38, power TG-R4-26, TG-R4-28, TG-R4-10 TG-R4-40 TG-R4-41, TG-R4-43, TG-R4-45 Min.* Max.** Min.* Max.** Min.*... -
Page 14: Fatal Error Indications And Error Code Messages
FATAL ERROR INDICATIONS AND ERROR CODE MESSAGES Fatal errors are indicated by function LEDs 1–7, which are all flashing at the same time. Each fatal error is identified by a code indicated by relay LEDs 1–5. ˜: LED is lit. ™: LED is off Relay Relay Relay... -
Page 15: Relay Functionality
Contact you representative for assistance. MECHANICAL INSTALLATION High casing Receiver models TG-R4-1 TG-R4-3 TG-R4-5 TG-R4-6 TG-R4-8 TG-R4-10... -
Page 16: Chapter 3: Guarantee, Service, Repairs And Maintenance
Tele Radio AB products are covered by a guarantee/warranty against material, construction and manufacturing faults. During the guarantee/warranty period, Tele Radio AB may replace the product or faulty parts. Work under guarantee/warranty must be carried out by Tele Radio AB or by an authorized service centre specified by Tele Radio AB. -
Page 17: Chapter 4: Regulatory Information
TG-R4-5, TG-R4-10, TG-R4-40, TG-R4-45 CE marking Hereby, Tele Radio AB, declares that the radio equipment type(s) listed above is/ are in compliance with Directive 2014/53/EU. The latest version of the complete EU Declaration of Conformity is available on the Tele Radio AB website, www.tele-radio.com. - Page 18 be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. ...
-
Page 19: Radio Module
To satisfy IC RF exposure requirements, a separation distance of 20 cm or more should be maintained between the antenna of this device and persons during device operation. To ensure compliance, operations at closer than this distance is not recommended. Afin d'assurer la conformité... -
Page 20: Annex A: Frequent Terms
ANNEX A: FREQUENT TERMS Function relay Standard relay, controlled by the buttons on the transmitter unit. Prevents a component from functioning when another component is functioning Interlocking or operating in a particular way. Latching relay The relay becomes active every time you press a button and remains active until functionality the button is pressed again. - Page 21 (This page has intentionally been left blank) - 21 -...
- Page 22 These installation instructions are subject to change without prior notice. Download the latest installation instructions from www.tele-radio.com...
