Tele Radio T50
Manual
Rev. IM-T50-001-A2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T50 and is the answer not in the manual?

Questions and answers

Related Manuals for Tele Radio T50

Summary of Contents for Tele Radio T50

  • Page 1 Tele Radio T50 Manual Rev. IM-T50-001-A2...

  • Page 2: Product Description

    ENGLiSh Product description ......................120 Preparations ........................121 Receiver ..........................123 Programming the receiver .....................126 Control of relay outputs: ....................133 Troubleshooting chart .....................135 Servicing and maintenance.....................136 PRODuct DEScRiPtiON IMPORTANT! In order to get the best out of your system it is important you take the time to read through the manual before you start to install and program your equipment.
  • Page 3 GenerAl informAtion programming and control via Gsm All programming and control of T50-02AGSM takes place using a normal mobile phone. T50-02AGSM supports the following networks: • EGSM900 • DCS1800 • PCS1900 range The range of the system is virtually unlimited. Where there is coverage on the GSM network, there is also communication with the receiver.

  • Page 4: Placement Of The Receiver

    plAcement of the receiver - Select a location, if possible, that is protected from the wind and weather. Avoid locations where the receiver may be exposed to abnormal moisture conditions, e.g. during high-pressure washing. - Fit the receiver with the cable couplings facing downwards.
  • Page 5 REcEivER Operating voltage: 7.5 – 24 V DC Power consumption: 50 – 200 mA Size: 120 x 120 x 45 mm Protection: IP 65 Climatic conditions: Max -30°C to +60°C Humidity 90 % 1. GSM module 2. SIM card holder For placement of the SIM card for the network in question 3 Connection terminal...

  • Page 6: Inserting The Sim Card

    visuAl And Audio indicAtions LED 1 (green) Flashes slowly Operating voltage is on. Flashes fast for 2 s Programming successful. Flashes fast for 10 s Alarm LED 2 (red) Flashing The receiver has a radio signal. Buzzer Continuous sound for 2 s Programming successful.

  • Page 7: Connecting The Operating Voltage

    1 2 3 4 7.5 – 24 V connecting the operating voltage 1. Connect the operating voltage to the voltage connection terminal. (Polarity insensitive). It takes approximately 15 seconds for the receiver to find the radio signal. connecting the relay 2. Connect the control signal (control voltage) to C. 3.

  • Page 8: Programming The Receiver

    PROGRaMMiNG thE REcEivER The receiver is programmed by sending SMS messages from a normal mobile phone. The SMS messages are sent to the receiver's telephone number, i.e. the telephone number linked to the SIM-card installed in the receiver. To avoid entering the receiver's telephone number for every SMS to be sent, we recommend that you save the number in the address book in the telephones used to control the receiver.
  • Page 9 proGrAmminG the messAGe centre number Prefix: A When you insert a new SIM card in the receiver, you must set the number for the message centre for the network in question. Note! Only necessary if the message centre number is not preprogrammed on the SIM-card. (#888888#A#1234567890#) SMS text: 1234567890 = Message centre number More information about how this is done can be found in the User Guide for your mobile phone or in the information booklet supplied with the SIM card.
  • Page 10 remove A Gsm user from the trAnsmitter Prefix: D This is how you remove a GSM telephone number, which should no longer be used to program or control the receiver. SMS text: (#888888#D#1234567890#) 1234567890 = The GSM telephone number to be removed settinG A time limit for control Prefix: S This is how you state the time that a user with time limited access is able...
  • Page 11 ActivAtion of proGrAmminG confirmAtion Prefix: B The function “programming confirmation” means that after each successful programming action, that is, after each SMS you have sent to the receiver which has been understood and accepted, you receive an SMS with the text “SUCCEED” sent to your mobile phone. If the programming action fails you receive an SMS with the text “FAILED”...
  • Page 12 chAnGe the pAssword password  Prefix: B All SMS messages sent to the receiver must include a six digit password. On delivery the password is 888888. The password can be changed to your own six digit code. We recommend that you do this. (#888888#B#777777#) SMS text: 888888 =...
  • Page 13 stAte the Gsm telephone user for AlArms Prefix: E This is how you state the GSM telephone number to which alarm informa- tion should be sent via SMS when one of the receiver's four alarm inputs is activated. A maximum of four telephone numbers can be programmed for alarm information. If you add a fifth number the first number programmed is overwritten. (#888888#E#1234567890#) SMS text: 1234567890 = The GSM telephone number to receive alarm messages remove the Gsm telephone user for AlArms Prefix: H This is how you remove a GSM telephone number that should no longer...
  • Page 14 ActivAtion of sms AlArm function Prefix: F In order for alarms to be sent to the telephone number you have stated according to section “State the GSM telephone user for alarms”, the alarm function must be activated according to the following. If you have programmed several telephone numbers to receive alarm information, the alarm function for all numbers is activated simultaneously.
  • Page 15 cONtROL OF RELay OutPutS: relAy  Activation via sms Prefix: J Relay 1 can be activated via SMS from an optional mobile phone with the help of a special password. The telephone number does not need to be programmed in advance in the receiver. This password on delivery is 666666 (also see the section “Change the password”).
  • Page 16 relAy  Note! In order to activate and deactivate relay output 2 your mobile phone must first be programmed in the receiver according to the section “Store a GSM-telephone user in the receiver”. Activation of relay  Prefix: T 1. Send an SMS with the format below to the receiver's telephone number. (#888888#T#) SMS text: – Relay 2 is activated and an SMS with the text “DEVICE ON” is sent to your mobile phone. deactivating of relay  Prefix: U 1. Send an SMS with the format below to the receiver's telephone number.

  • Page 17: Troubleshooting Chart

    tROuBLEShOOtiNG chaRt If the equipment does not work as it should, please check the points set out below. MALFUNCTION POSSIBLE CAUSES ACTION Nothing happens when I Check the connection of The receiver is connected start the receiver. the receiver. incorrectly. Incorrect supply voltage to Check the supply voltage to the receiver.

  • Page 18: Servicing And Maintenance

    NOTE! The warranty does not apply to faults that have arisen due to modifications to products, incorrect installation or abnormal use. recyclinG, scrAppinG T50-02AGSM systems and any accessories and spare parts no longer in use should be scrapped and recycled according to local environmental regulations.  CE Declaration of conformity for Tele Radio AB radio-controlled systems...
  • Page 19 TELE RADIO AB Sweden, Main office Tel. +46 (0)31-748 54 60 www.tele-radio.com e-mail: info@tele-radio.com TELE RADIO AB TELE RADIO SVERIGE TELE RADIO OÜ TELE RADIO GmbH Sweden, Main office Sweden Estonia Germany Tel. +46 (0)31-748 54 60 Tel. +46 (0)31-724 98 00 Tel.
