Summary of Contents for Tele Radio R4-01

  • Page 1 END USER INSTRUCTIONS Receivers: R4-26, R4-28, R4-01, R4-03, R4-41, R4-43 R4-06, R4-08, safe smart strong R4-36, R4-38 ED-TG2-RX101-EN-v04 Language: English (original)
  • Page 2 ©Tele Radio AB Datavägen 21 SE-436 32 Askim Sweden Phone: +46 (0)31 748 54 60...
  • Page 3: Table Of Contents

    End user instructions│ R4│ CHAPTER 1: INTRODUCTION 1.1  About this document 1.2  About Tiger TG2 systems CHAPTER 2: SAFETY 2.1  Warnings & restrictions CHAPTER 3: TECHNICAL DATA 3.1  Receiver specifications 3.2  Current consumption CHAPTER 4: PRODUCT GENERAL DESCRIPTION 4.1  Receiver description 4.2  Mechanical installation CHAPTER 5: STATUS AND ERROR INDICATIONS 5.1  Function LEDs indication in normal operation 5.2  CANopen run status 5.3  CANopen error status...
  • Page 4: Chapter 1: Introduction

    READ ALL INSTRUCTIONS AND WARNINGS CAREFULLY BEFORE OPERATING THE PRODUCTS. These End user instructions have been published by Tele Radio AB and are not subject to any guarantees. The End user instructions may be withdrawn or revised by Tele Radio AB at any time and without further notice. Corrections and updates will be added to the latest version of the manual.
  • Page 5 End user instructions│ R4│ Chapter 1: Introduction Tele Radio AB products are covered by a warranty against material, construction, or manufacturing faults. See "Chapter 7: Warranty, service, repairs, and maintenance". ED-TG2-RX101-EN-v04...
  • Page 6: About This Document

    Before installing or operating the product, read the corresponding documentation carefully. Tele Radio AB's product range is composed of transmitters, receivers, and accessories intended for use together as a system. These End user instructions cover general safety issues, main technical specifications, and standard operating instructions.
  • Page 7: About Tiger Tg2 Systems

    • 4 3 3 M H z f r e q u e n c y r a n g e Casing type Main board Expansion boards Bus system High 12–24 V AC/DC, 10-relay ADIO CAN/ 48–230 V AC (4 relays) J1939 7 relays R4-01 ● – ● – – – R4-06 ● – ● ● – –...
  • Page 8: Chapter 2: Safety

    The following information is intended for use as a complement to applicable local regulations and standards. IMPORTANT! Tele Radio AB remote controls are often built into wider applications. These systems should be equipped with:     • a wired emergency stop where necessary     •...
  • Page 9 End user instructions│ R4│ Chapter 2: Safety Always follow operating and maintenance instructions as well as all applicable safety procedures and requirements. Do not open the receiver encapsulation unless you are qualified. You must satisfy the age requirements in your country for operating the equipment.
  • Page 10 End user instructions│ R4│ Chapter 2: Safety Wipe off dust using a clean, slightly damp cloth. Never use cleaning solutions. Check the encapsulation, foils and cable for damages every day. If you use the product although the encapsulation or foil is damaged, moisture can cause serious damage to the electronics.
  • Page 11: Chapter 3: Technical Data

    3 . 1     R e c e i v e r s p e c i f i c a t i o n s 3 . 1 . 1     4 3 3 M H Z R4-01 R4-06...
  • Page 12 End user instructions│ R4│ Chapter 3: Technical data R4-01 R4-06 R4-36 R4-26 R4-41 Weight (typical) 800 g / 950 g / 2.1 lbs 800 g / 1.8 lbs 1.8 lbs 3 . 1 . 2     9 1 5 M H Z R4-03 R4-08 R4-38 R4-28...
  • Page 13: Current Consumption

    * Potential free means that a supply voltage is needed to get voltage out of a relay (e.g. via the included connection comb). 3 . 2     C u r r e n t c o n s u m p t i o n Input R4-01, R4-03, R4-06, R4-08 R4-36, R4-38 power...
  • Page 14: Chapter 4: Product General Description

    End user instructions│ R4│ Chapter 4: Product general description CHAPTER 4: PRODUCT GENERAL DESCRIPTION The pictures shown in this chapter are for illustrative purposes only. 4 . 1     R e c e i v e r d e s c r i p t i o n 4 .
  • Page 15 End user instructions│ R4│ Chapter 4: Product general description 4 . 1 . 3     R 4 - 2 6 , R 4 - 4 1 1. Cable gland M25x1.5 2. BNC connector for external antenna 4 . 1 . 4     R 4 - 2 8 , R 4 - 4 3 1.
  • Page 16: Mechanical Installation

    End user instructions│ R4│ Chapter 4: Product general description 4 . 2     M e c h a n i c a l i n s t a l l a t i o n NOTE: For mounting on a wall or equipment, use 4 M5x30 mm screws or equivalent fastening method.
  • Page 17 End user instructions│ R4│ Chapter 4: Product general description 4 . 2 . 3     R 4 - 2 6 , R 4 - 4 1 ( L O W C A S I N G , B N C C O N N E C T O R ) 4 .
  • Page 18: Chapter 5: Status And Error Indications

    End user instructions│ R4│ Chapter 5: Status and error indications CHAPTER 5: STATUS AND ERROR INDICATIONS 5 . 1     F u n c t i o n L E D s i n d i c a t i o n i n n o r m a l o p e r a t i o n Color Flashing Indicates ○...
  • Page 19: Canopen Run Status

    End user instructions│ R4│ Chapter 5: Status and error indications 5 . 2     C A N o p e n r u n s t a t u s NOTE: Applies to receiver models: R4-26, R4-28, R4-41, R4-43 Colour Flickering Single flash Blinking...
  • Page 20: Fatal Error Indications And Error Code Messages

    End user instructions│ R4│ Chapter 5: Status and error indications 5 . 4     F a t a l e r r o r i n d i c a t i o n s a n d e r r o r c o d e m e s s a g e s Fatal errors are indicated by function LEDs 1–7, which are all flashing at the same time.
  • Page 21 End user instructions│ R4│ Chapter 5: Status and error indications Relay LED /LED Description Relay Relay Relay Relay Relay LED1/ LED2/ LED3/ LED4/ LED5/ LED17 LED11 LED12 LED13 LED14 (red) (red) (red) (red) (red) Wrong target software version in ˜ ˜ ˜...
  • Page 22: Show Digital Input Status On The Transmitter

    End user instructions│ R4│ Chapter 5: Status and error indications 5 . 5     S h o w d i g i t a l i n p u t s t a t u s o n t h e t r a n s m i t t e r NOTE: This function requires duplex communication to be activated.
  • Page 23 End user instructions│ R4│ Chapter 5: Status and error indications NOTE: LED = DI  +2 number number Ex. R4-06: If pin 84 is connected to pin 85, LED 5 will light on the transmitter when DI 3 is activated. 84 = GND 85 = DI 3 ED-TG2-RX101-EN-v04...
  • Page 24: Chapter 6: Operation

    End user instructions│ R4│ Chapter 6: Operation CHAPTER 6: OPERATION 6 . 1     G e n e r a l i n f o r m a t i o n To control a receiver, the transmitter must be registered and logged in to the receiver.
  • Page 25: Chapter 7: Warranty, Service, Repairs, And Maintenance

    Tele Radio AB products are covered by a warranty against material, construction and manufacturing faults. During the warranty period, Tele Radio AB may replace the product or faulty parts. Work under warranty must be performed by Tele Radio AB or by an authorized service center specified by Tele Radio AB.
  • Page 26: Chapter 8: Regulatory Information

    R4-01, R4-06, R4-26, R4-36, R4-41 8 . 1 . 1     C E M A R K I N G Hereby, Tele Radio AB, declares that the radio equipment type(s) listed above is/are in compliance with the Radio Equipment Directive 2014/53/EU.
  • Page 27 End user instructions│ R4│ Chapter 8: Regulatory information 8 . 2 . 1     F C C   S T A T E M E N T This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that...
  • Page 28 End user instructions│ R4│ Chapter 8: Regulatory information 8 . 2 . 2     I C S T A T E M E N T This product complies with Industry Canada's licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of device.
  • Page 29 End user instructions│ R4│ Chapter 8: Regulatory information Afin d'assurer la conformité aux exigences de la IC en matière d'exposition aux RF, une distance de séparation d'au moins 20 cm doit être maintenue entre l'antenne de cet appareil et toute personne à proximité pendant le fonctionnement de l'appareil.
  • Page 30: Eac

    Applies to: R4-01, R4-06, R4-26, R4-36, R4-41 8 . 3 . 1     E A C S T A T E M E N T ( Д Е К Л А Р А Ц И Я Е А С ) This product is declared as compliant within Eurasian Economic Union (EAC).
  • Page 31: Annex A: Index

    End user instructions│ R4│ Annex A: Index ANNEX A: INDEX About R4 receivers AEC Statement ANATEL Statement Antenna 11-12 Bus system 11-12 CE marking Connector 11-12 Current consumption Digital input indications on the transmitter Dimensions 11-12 EIRP 11-12 Error indications CANopen Fatal errors FCC statement FCC/IC labels...
  • Page 32 End user instructions│ R4│ Annex A: Index IP code 11-12 Maintenance Mounting dimensions Receiver Number of channels Number of digital inputs 11-12 Number of digital outputs 11-12 Number of transistor outputs 11-12 Operating temperature 11-12 Radio communication 11-12 Radio frequency band 11-12 Radio frequency output power 11-12...
  • Page 33 End user instructions│ R4│ Annex A: Index Operation WEEE directive Weight 12-13 ED-TG2-RX101-EN-v04...
  • Page 34 safe smart strong These End user instructions are subject to change without prior notice. Download the latest End user instructions from www.tele-radio.com .
