Note: 1. 10/100Base-TX Ethernet port
2. RJ45 port status LED
3. System status LED
4. DC power port
Heat Dissipation
The RG-ES05 adopts natural heat dissipation, thereby ensuring normal function of the device. Maintain a minimum
clearance of 100 mm (3.94 in.) around the device. It is recommended to clean the device once every 3 months to avoid
dust from blocking vents.
LEDs
LED
System status LED
RJ45 port status LED
1.2 RG-ES08
Technical Specifications
Model
Ports
Power Supply
Ruijie 5/8-Port Plastic Series Switches Hardware Installation and Reference Guide
Panel Identification
1-5
RG-ES08
Supports 8 10/100 Base-TX auto-sensing Ethernet ports.

AC input
Rated voltage range: 100 VAC to 240 VAC
Maximum voltage range: 90 VAC to 264 VAC
Frequency: 50/60 Hz
Rated current: 0.3 A

Adapter output
Rated voltage range: 5 VDC
Rated current range: 0.6 A
State Meaning
Off The switch is powered off.
Solid on The switch is operational.
Off The port is not connected.
Solid on The port is connected at 10/100 Mbps.
The port is receiving or sending traffic at 10/100
Blinking
Mbps.
