Security Standards
Earth Leakage
Current
Dimensions
(W x D x H)
Weight
(With Package)
The RG-ES05G switch is a class A product. In a domestic environment, this product may cause radio interference in
which case the user may be required to take adequate measures.
Product Appearance
On the front panel, the RG-ES05G Ethernet switch provides five 10/100/1000Base-T Ethernet ports and a DC power port.
Figure 1-5 Appearance of RG-ES05G
Front Panel
Figure 1-6 Front Panel of RG-ES05G
Ruijie 5/8-Port Plastic Series Switches Hardware Installation and Reference Guide
GB4943-2011
EN 62638-1
≤ 1.5mA
108.1 mm x 64 mm x 24.8 mm (4.26 in. x 2.52 in. x 0.98 in.)
0.2 kg (0.44 lbs)
