Henny Penny FPG-615 Technical Bulletin
Hide thumbs
Also See for FPG-615:
- Service instructions manual (124 pages) ,
- Service instructions manual (20 pages) ,
- Operator's manual (86 pages)
Advertisement
Quick Links
Technical Bulletin
Subject: Gas Retrofit Kit for FlexFusion Combisteamer
Date: 11/09/2018
Region Impacted: Global
Models Affected: FPG-615, FPG-621, FPG-115, FPG-121, FPG-215, FPG-221
Summary:
As part of continuous improvement, optional gas retrofit kits are available for the FlexFusion
Combisteamers with serial numbers prior to 18200794 (units manufactured after February 2018).
This upgrade:
-
Improves the performance of the ignition module with software version 1.71.
-
Improves the reliability of transformer voltage.
-
Adds a condensate protection rim to protect the power supply board from water dripping from
the humidity probe.
Part Numbers
Order the following stock to upgrade the gas FlexFusion Combisteamer:
Part #
MM10019319
-
MM10017377
-
MM203999
-
MM201176
-
MM201177
-
10018348
-
MM10019320
-
MM10017376
-
MM203999
-
MM201176
-
MM201177
-
10018348
-
Indented items or items with a dash (–) are included in non-indented part numbers.
NOTE: All components from the kit must be installed and software must be version 1.71 or higher for
full performance. Software version 1.71 and higher are available for download on the Extranet.
Description
110V CSA Gas Retrofit Kit
-
Ignition Module – 120V
-
Transformer
-
Glow electrode
-
Ionization electrode
-
Condensate protection rim
-
Gaskets (set of 3)
230V CE Gas Retrofit Kit
-
Ignition Module - 230V
-
Transformer
-
Glow electrode
-
Ionization electrode
-
Condensate protection rim
-
Gaskets (set of 4)
Page 1 of 5
Stocking Level
Qty.
n/a
1
n/a
1
n/a
1
n/a
1
n/a
1
n/a
1
n/a
1
n/a
1
n/a
1
n/a
1
n/a
1
n/a
1
n/a
1
n/a
1
Advertisement
Related Manuals for Henny Penny FPG-615
Summary of Contents for Henny Penny FPG-615
- Page 1 Subject: Gas Retrofit Kit for FlexFusion Combisteamer Date: 11/09/2018 Region Impacted: Global Models Affected: FPG-615, FPG-621, FPG-115, FPG-121, FPG-215, FPG-221 Summary: As part of continuous improvement, optional gas retrofit kits are available for the FlexFusion Combisteamers with serial numbers prior to 18200794 (units manufactured after February 2018).
- Page 2 Procedures Explosion and Fire Risk • To avoid personal injury and product damage, check gas connection line and all gas parts for leaks at operating pressure. • Prior to servicing the unit, turn the power switch to the off position and remove electrical power from the product.
- Page 3 Removing the Solenoid Valve 1. Remove supply pipe from Venturi pipe (e). 2. Remove three fastening screws (b) from Venturi pipe. 3. Remove solenoid valve (a). 4. Detach gas hose. NOTE: When reinstalling, apply threadlocker to screws of gas hose (f) and torque to 26 in-lb (3 Nm). Apply antiseize paste to Venturi pipe screws (b) and torque to 26 in-lb (3 Nm).
- Page 4 Removing the Gas Burner Explosion and asphyxiation risk To avoid personal injury and product damage, check seals for damage and replace • damaged seals. 1. Detach electrical connections on electrodes. 2. Dismount nuts (a). 3. Remove gas burner. NOTE: When reinstalling, replace gasket seals, apply anti-seize paste to screws, and torque screws to 53 in-lb (6 Nm).
-
Page 5: Warranty
Removing the Transformer FPG-215 and FPG-221 Tabletop Unit 1. Unplug connector from transformer. 2. Remove both screws. 3. Remove transformer. To install, reverse procedures and read notes. Warranty The Flexfusion Combisteamer gas retrofit kit includes a 90 day parts warranty from the date of install. These kits are an option for operators to update units to current production.
