- Page 1 iWJ Read the operating instructions prior to commissioning FLEXFUSION PLATINUM FLEXFUSION GOLD FPE 615 Stacking kit FPE 621 FPE 115 FPE 121 FM06-148A en-US...
- Page 2 Henny Penny Corporation P.O.Box 60 Eaton,OH 45320 Phone +1 937 456-8400 Fax +1 937 456-8402 Toll free in USA Phone +1 937 417-8417 Fax +1 937 417-8434 www.hennypenny.com Installation instructions...
-
Page 3: Table Of Contents
Directory of contents 1 Introduction ................. 5 1.1 About this manual ................ 5 1.1.1 Explanation of signs .................. 6 1.2 Use of the unit ................... 7 1.3 Warranty .................... 7 2 Safety instructions ............. 8 3 Description of the unit ............ 9 4 Scope of delivery .............. 10 5 Proceeding with installation .......... 12 5.1 Fastening the unit combination to the floor ... - Page 4 Directory of contents Installation instructions...
-
Page 5: 1 Introduction
Introduction 1 Introduction 1.1 About this manual The installation instructions are part of the unit and contain information on safe installation of the unit. Observe the following notes and adhere to them: • Read the installation instructions completely prior to installation. •... -
Page 6: Explanation Of Signs
Introduction 1.1.1 Explanation of signs Imminent danger DANGER Failure to comply will lead to death or very severe injuries. Potential danger WARNING Failure to comply can lead to death or very severe injuries. Dangerous situation CAUTION Failure to comply can lead do slight to moderately severe injuries. Property damage NOTICE Failure to comply can cause property damage. -
Page 7: Use Of The Unit
Introduction 1.2 Use of the unit This unit is intended to be used solely for commercial purposes, particularly in commercial kitchens. 1.3 Warranty The warranty is void and safety is no longer assured in the event of: • Improper conversion or technical modifications of the unit, •... -
Page 8: 2 Safety Instructions
Safety instructions 2 Safety instructions The unit complies with applicable safety standards. Residual risks associated with operation or risks resulting from incorrect operation cannot be ruled out and are mentioned specifically in the safety instructions and warnings. The installation fitter must be familiar with regional regulations and observe them. -
Page 9: 3 Description Of The Unit
Description of the unit 3 Description of the unit Image: Description of the individual parts a Outgoing air pipe holder g Cover panel (right) b Extension for outgoing air pipe h Cover plate for unit Gen 2 (only available once) c Seal for outgoing air pipe i Cover panel (front) d Outgoing air pipe diverter... -
Page 10: 4 Scope Of Delivery
Scope of delivery 4 Scope of delivery The following parts are included in the delivery. Prior to the installation, check that the parts are complete and undamaged. Scope of delivery Item Image Name Article number Quantity Outgoing air 866864 pipe holder Exhaust air pipe 935634 for 6 top... - Page 11 Scope of delivery Item Image Name Article number Quantity Cover plate 802401 Adhesive tape 303503 Snap nut, M4 208025 Screw, M4x10 118005 Screw, M4x16 101120 Nut, M4 113082 Lock washer, 4 121031 Washer, 4 120017 Nut, M6 113091 Lock washer, 6 121033 Installation instructions...
-
Page 12: 5 Proceeding With Installation
Proceeding with installation 5 Proceeding with installation Risk of fatal injury from falling unit DANGER • Do not stand under a suspended load. • Cordon off danger zone in compliance with regulations. Risk of property damage and personnel injury from tipping unit CAUTION •... -
Page 13: Fastening The Unit Combination To The Floor
Proceeding with installation 5.1 Fastening the unit combination to the floor Falling over is possible with the following unit combinations WARNING Floor mounting is mandatory for the following unit combinations. • FPECOD121-621A • FPECOD115-621 • FPECOD121-615 • FPECOD115-615 Risk of accident from insufficient fastening WARNING Unit can tip over •... - Page 14 Proceeding with installation Floor without steam barrier In the case of floors without a steam barrier, the floor plates are bolted to the floor using the bolts provided. Image: A: Position of floor plate; B: floor plate bolted to the floor a Cap nut d Floor plate b Holding plate...
- Page 15 Proceeding with installation Image: A: Position of floor plate; B: floor plate glued to the floor a Cap nut d Floor plate b Holding plate e Unit leg c Upright bolt Prerequisite Floor capable of accommodating the weight of the unit Floor must be clean and suitable for the manner fastening Unit set up and aligned in accordance with the planning drawing 1.
-
Page 16: Preparing To Place In Position
Proceeding with installation 5.2 Preparing to place in position 5.2.1 Preparing the underframe (optional) Risk of property damage and personal injury from slide-in rails CAUTION that are too high. • The underframe under an attached stacking kit must be a maximum of 270 mm high. -
Page 17: Preparing The Bottom Combisteamer
Proceeding with installation 5.2.3 Preparing the bottom Combisteamer Prerequisite Unit unpacked Electrical connection line dead Water supply line disconnected from the supply network Wastewater connection prepared Stacking kit checked for completeness and made ready Underframe prepared (optional) 1. Attach the adapter plate. 2. -
Page 18: Installing The Combisteamer (Bottom)
Proceeding with installation Image: Outgoing air pipe diverter with locking mechanism on adapter plate (arrow) a Seal b Outgoing air pipe diverter c Adapter plate Prerequisite Adapter plate attached 1. Put the seals onto the outgoing air pipe diverter. 2. Put the outgoing air pipe diverter onto the unit's outgoing air outlet. 3. -
Page 19: Placing The Top Combisteamer
Proceeding with installation 5.4 Placing the top Combisteamer Risk of injury from the unit tilting WARNING Support the unit to prevent the unit from tilting. Risk of property damage from improper lowering of the unit NOTICE Take care not to damage the unit's locking unit. The manufacturer recommends the use of flange feet for the top combi INFORMATION steamer. -
Page 20: Attaching The Anti-Tilt Unit
Proceeding with installation 3. On a gas unit: Connect the gas connection pipe. 4. Lift the top Combisteamer with a lifting truck and place it on the installed adapter plate. Pay attention to the positioning of the unit legs on the upright bolts. -
Page 21: Attaching The Outgoing Air Pipe
Proceeding with installation 2. Press the angles to the wall. If necessary, compensate for any unevenness with suitable shims. 3. Depending on the type of fastening required, fasten the angles rigidly and securely to the wall with suitable fastening materials. Anti-tilt unit is installed. -
Page 22: Attaching The Cover Panels
Proceeding with installation 6. Complete both start-up operation reports. 5.8 Attaching the cover panels 5.8.1 Assembling the front cover panel Image: Unit right hinged a Screw c Plate b Nut d Cover panel Image: Combisteamer top unit Gen 2 right hinged Installation instructions... - Page 23 Proceeding with installation Image: Combisteamer top unit Gen 1 right hinged Right-hinged unit Gen 2 1. Break out the cut-out on the right-hand side of the cover at the pre-punched point to enlarge it. 2. Close the cut-out on the left side of the cover panel. 3.
-
Page 24: Attaching The Front Cover Panel
Proceeding with installation 5.8.2 Attaching the front cover panel Image: Cover panel a Adapter plate c Nut b Screw d Cover panel Prerequisite Both units are not live Combisteamers connected together Water connection made 1. Put the nut on the holder. 2. -
Page 25: Attaching The Cover Panel On The Right
Proceeding with installation 5.8.3 Attaching the cover panel on the right Image: Cover panel a Cover panel c Nut b Screw d Adapter plate Prerequisite Both units are not live Combisteamers connected together Water connection made 1. Put the nut on the holder. 2. -
Page 26: Attaching The Cover Panel On The Left
Proceeding with installation 5.8.4 Attaching the cover panel on the left Image: Cover panel a Cover panel c Adapter plate b Screw d Snap nut Prerequisite Both units are not live Combisteamers connected together Water connection made Cover panel on the right attached 1. -
Page 27: Fitting The Grease Drain Hose Holder
Proceeding with installation 5.8.5 Fitting the grease drain hose holder The holder can be attached to the left and right side of the unit. INFORMATION No additional screws are required. Use the screws that have been removed. Unit disconnected from power supply. 1. - Page 28 Proceeding with installation Installation instructions...
