Motherboard Features

CPU
•
A2SAP-L1: Intel® Atom SoC E3940 Processor, Quad Core, 2 MB L2 Cache, 1.6GHz-1.8GHz, 9.5W
Memory
•
Integrated memory controller supports up to 8GB of DDR3L 1867MHz Non-ECC 204-pin SO-DIMM
DIMM Size
•
Single channel Non-ECC SO-DIMM, DDR3L 1333/1600/1867MHz up to 8GB
Expansion Slots
•
One Half-Size Mini PCIe Slot (supports PCIe x1 Gen2 / one USB 2.0)
•
One M.2 Slot (B-KEY 2242/3042) (SATA 3.0 / PCIe x1 Gen2 / USB 2.0)
Network
•
Dual Intel I210 controller
Graphics
•
Intel® HD Graphics GT Series
I/O Devices
•
COM Port
•
SATA Port
•
Audio Port
•
SMBus Box Header
•
8-bit GPIO
Peripheral Devices
•
Two USB 3.0 ports on two box headers (JUSB1/JUSB2)
•
Four USB 2.0 ports on two box headers (USB0/1, USB2/3)
BIOS
•
128Mb SPI AMI BIOS
®
•
ACPI 6.0, SMBIOS 3.0, PCI F/W 3.0, UEFI 2.5, BIOS rescue hot-key, RTC (Real Time Clock) wakeup
Note: The table above is continued on the next page.
Motherboard Features
•
Features: OpenGL 5.0, DirectX 12, OpenCL 2.1
•
Hardware Decode: AVC/H.264, MPEG2, VC1/WMV9, JPEG/MJPEG,
HEVC/H.265, VP8, VP9, MVC
•
Hardware Encode: AVC/H.264, JPEG/MJPEG, HEVC/H.265, VP8, VP9, MVC
•
Display: HDMI 1.4 (resolution up to 3840x2160 at 30Hz), LVDS (dual channel
48-bit, resolution up to 1920x1200 at 60Hz)
•
Two COM ports via one box header (JCOM1 supports two RS232/RS422/RS485)
•
One SATA 3.0 port (I-SATA1)
•
One HD Audio box header with Mic-in/Headphone-out (Realtek ALC888S)
•
One SMBus box header
•
One 8-bit GPIO box header
