2.4 Rear I/O Ports
See Figure 2-1 below for the locations and descriptions of the various I/O ports on the rear
of the motherboard.
JPWR1
JMD1
Figure 2-1. Rear I/O Port Locations and Definitions
JUSB1
JHDMI1
JUSB2
SRW2
LED1
A2SAP-L1
REV:1.00
DESIGNED IN USA
JF1
1
2
3
Rear I/O Ports
#
Description
1.
LAN1
2.
LAN1LED1
3.
I-SATA1
4.
HDMI
JLAN1
JLAN1LED1
JLPC
SRW1
JMP1
JCOM1: COM1/COM2
J3: AUDIO FP
5
6
7
4
#
Description
5.
USB1
6.
USB2
7.
PWR1
25
Chapter 2: Installation
USB 0/1
BT1
JLCDPWR1
