Super A2SAP-L1 User's Manual
PCIe/PCI/PnP Configuration
The following PCI information will be displayed:
•
PCI Bus Driver Version
•
PCI Devices Common Settings
Above 4G Decoding (Available if the system supports 64-bit PCI decoding)
Select Enabled to decode a PCI device that supports 64-bit in the space above 4G
Address. The options are Enabled and Disabled.
NVMe Firmware Source
The feature determines which type of NVMe firmware should be used in your system. The
options are Vendor Defined Firmware and AMI Native Support.
M.2 Slot B-Key (JMD1 OPROM)
Use this feature to select the firmware type to be loaded for the add-on card in this slot. The
options are Disabled, Legacy and EFI.
Mini PCIe OPROM (JMP1 OPROM)
Use this feature to select the firmware type to be loaded for the add-on card in this slot. The
options are Disabled, Legacy and EFI.
Onboard LAN Option ROM
Use this feature to select the firmware type to be loaded for the add-on card in this slot. The
options are Disabled, Legacy and EFI.
Onboard Video Option ROM
Use this feature to select the firmware type to be loaded for the add-on card in this slot. The
options are Disabled, Legacy and EFI.
Network Stack
Select Enabled to enable Preboot Execution Environment (PXE) or Unified Extensible
Firmware Interface (UEFI) for network stack support. The options are Disabled and Enabled.
IPv4 PXE Support
Select Enabled to enable IPv4 PXE boot support. The options are Disabled and Enabled.
IPv6 PXE Support
Select Enabled to enable IPv6 PXE boot support. The options are Disabled and Enabled.
PXE boot wait time
Use this option to specify the wait time to press the ESC key to abort the PXE boot. Press
"+" or "-" on your keyboard to change the value. The default setting is 0.
