2.8 LED Indicators

LAN Port LED
There is one LAN port (JLAN1) on the I/O back panel of the motherboard. The LAN port has
two LEDs (located at JLAN1LED1) right next to it. The green LED indicates activity, while the
other Link LED may be green, amber, or off to indicate the speed of the connection.
LAN1 LED
(Connection Speed
Indicator)
LED Color
Off
Green
Amber
Power LED
LED1 is the Power LED. In S0 mode, this LED will be solid green. In S3/S4/S5 modes, this
LED will be solid red.
JPWR1
JUSB1
JUSB2
SRW2
JMD1
JF1
Definition
10 Mb/s
100 Mb/s
1 Gb/s
Onboard Power LED Indicator
LED Color Definition
System Off
Off (power cable not
connected)
Solid Green S0 mode
Solid Red S3/S4/S5 modes
JLAN1LED1
JHDMI1
JLPC
SRW1
JMP1
2
LED1
JCOM1: COM1/COM2
A2SAP-L1
REV:1.00
DESIGNED IN USA
41
JLAN1LED1
Pin Definition
Pin Definition
1 I210ATX1_ACT_N
2 P3V35B_I210ATX1
3 I210ATX1_1000_N
4 I210ATX1_100_N
1
JLAN1
USB 0/1
BT1
JLCDPWR1
J3: AUDIO FP
Chapter 2: Installation
1. JLAN1 Port LED
2. Power LED
