Wait For "F1" If Error
This feature forces the system to wait until the F1 key is pressed if an error occurs. The
options are Disabled and Enabled.
INT19 Trap Response
Interrupt 19 is the software interrupt that handles the boot disk function. When this feature
is set to Immediate, the ROM BIOS of the host adapters will "capture" Interrupt 19 at boot
up immediately and allow the drives that are attached to these host adapters to function as
bootable disks. If this feature is set to Postponed, the ROM BIOS of the host adapters will not
capture Interrupt 19 immediately and allow the drives attached to these adapters to function
as bootable devices at boot up. The options are Immediate and Postponed.
Re-try Boot
If this feature is enabled, the BIOS automatically reboots the system from a specified boot
device after its initial boot failure. The options are Disabled, Legacy Boot, and EFI Boot.
Power Configuration
Watch Dog Function
If enabled, the Watch Dog Timer allows the system to reset or generate NMI based on jumper
settings when it is expired for more than five minutes. The options are Disabled and Enabled.
Power Button Function
This feature controls how the system shuts down when the power button is pressed. Select 4
Seconds Override for the user to power off the system after pressing and holding the power
button for four seconds or longer. Select Instant Off to instantly power off the system as soon
as the user presses the power button. The options are Instant Off and 4 Seconds Override.
Restore on AC Power Loss
Use this feature to set the power state after a power outage. Select Stay Off for
the system power to remain off after a power loss. Select Power On for the system
power to be turned on after a power loss. Select Last State to allow the system to
resume its last power state before a power loss. The options are Stay Off, Power On,
and Last State.
CPU Configuration
The following CPU information is displayed:
•
Intel (R) Atom (TM) Processor E3940 @ 1.60GHz
•
CPU Signature
•
Microcode Patch
•
Max CPU Speed
