DLP LightCrafter Single DLPC900 EVM Overview

1.4 Other Items Needed for Operation

The DLP LightCrafter Single DLPC900 EVM is a flexible, ready-to-use evaluation module which, when coupled
to one of the DLP LightCrafter DMD EVMs, enables the sending of customer created patterns from the DLPC900
Controllers to the attached DMD for display at the customer determined pattern rates. The DLP LightCrafter
Single DLPC900 EVM and the DMD EVMs are offered for purchase separately so that customers can determine
which elements they wish to piece together for their own application evaluation system.
The following items are not included with the EVM and need to be purchased separately if needed for customer
evaluation:
• Power supply - see Section 5.1
• USB cable: A to B USB cable
®
• HDMI or DisplayPort
• Illumination module or source
• Illumination and projection optics
10 DLP® LightCrafter™ Single DLPC900 Evaluation Module (EVM) User's Guide
External Power Supply Requirements for details
™
cable connected to a graphics or video source (if using video input)
