Altronix ALTV248220 Series Installation Manual page 11

1.25" (31.75mm)
1.5"
(12.7mm)
1"
(25.4mm)
4.5" (114.3mm)
ALTV248220 Series Installation Guide
Enclosure Dimensions (H x W x D) for:
• ALTV248300220 • ALTV248300CB220
12.25" x 7.25" x 4.5" (311.15mm x 184.15mm x 114.3mm)
0.5" (12.7mm)
1" (25.4mm)
0.88" (22.4mm)
7.5" (190.5mm)
0.5" (12.7mm)
7.5" (190.5mm)
5.75" (146.1mm)
1.25" (31.75mm)
4.5" (114.3mm)
1" (25.4mm)
0.88" (22.4mm)
- 11 -
