220VAC Isolated Series
CCTV Power Supplies
Models Include:
ALTV248Hi220
- 24VAC @ 12.5A total output.
- Eight (8) 1.75A Fuse Protected
Isolated Outputs.
ALTV248Mi220
- 24VAC @ 12.5A total output.
- Eight (8) 1.6A Fuse Protected
Isolated Outputs.
ALTV2416i220
- 24VAC @ 25A total output.
- Sixteen (16) 1.75A Fuse Protected
Isolated Outputs.
Installation Guide
Rev. 041112
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
ALTV248CBHi220
- 24VAC @ 12.5A total output.
- Eight (8) 1.75A PTC Protected
Isolated Outputs.
ALTV248CBMi220
- 24VAC @ 12.5A total output.
- Eight (8) 1.6A PTC Protected
Isolated Outputs.
ALTV2416CBi220
- 24VAC @ 25A total output.
- Sixteen (16) 1.75A PTC Protected
Isolated Outputs.
More than just power.
TM
Advertisement
Related Manuals for Altronix 220VAC Series
Summary of Contents for Altronix 220VAC Series
- Page 1 220VAC Isolated Series CCTV Power Supplies Models Include: ALTV248Hi220 ALTV248CBHi220 - 24VAC @ 12.5A total output. - 24VAC @ 12.5A total output. - Eight (8) 1.75A Fuse Protected - Eight (8) 1.75A PTC Protected Isolated Outputs. Isolated Outputs. ALTV248Mi220 ALTV248CBMi220 - 24VAC @ 12.5A total output.
- Page 2 Overview: Altronix Isolated CCTV Power Supplies provide 24VAC distributed via eight (8) or sixteen (16) fuse or PTC protected isolated outputs for powering CCTV cameras, heaters, and other video accessories. Isolated Power Supply Reference Chart: Output 220VAC Total Number PTC Protected...
-
Page 3: Terminal Identification
CAUTION: Equipment to be installed/serviced by authorized/trained personnel only. Shut branch circuit power before installing/servicing equipment. WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture. This installation should be made by qualified service personnel and should conform to the National Electrical Code and all local codes. - Page 4 - 4 - Isolated 220 Series Installation Guide...
- Page 5 Isolated 220 Series Installation Guide - 5 -...
- Page 6 - 6 - Isolated 220 Series Installation Guide...
- Page 7 Enclosure Dimensions (H x W x D) for: • ALTV248Mi220 • ALTV248CBMi220 8.5” x 7.5” x 3.875” (215.9mm x 191mm x 98.4mm) 3.63” (92.2mm) 1.25” (31.75mm) 7.25” (184.15mm) 1.25” (31.75mm) 0.6” (15.24mm) 0.6” (15.24mm) 1.25” (31.75mm) 1.25” (31.75mm) 0.6” (15.24mm) 0.6” (15.24mm) 3.85”...
- Page 8 1.0” 1.0” 10.5” (266.7mm) (25.4mm) (25.4mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIIsolated 220 Series...
