Installation Manual
ALTV248UL3 Series
CCTV Power Supplies
Installation Guide
Models Include:
ALTV248UL3
- 24VAC @ 3.5A (85VA)
or 28VAC @ 3A (85VA).
- Eight (8) Fuse Protected Outputs.
- Factory installed 3-wire line cord.
ALTV248175UL3
- 24VAC @ 7A (175VA)
or 28VAC @ 6.25A (175VA).
- Eight (8) Fuse Protected Outputs.
- Factory installed 3-wire line cord.
ALTV248300UL3
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (280VA).
- Eight (8) Fuse Protected Outputs.
- Factory installed 3-wire line cord.
ALTV248300ULM3
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (280VA).
- Eight (8) Fuse Protected Outputs.
- Factory installed 3-wire line cord.
ALTV248600UL3
- 24VAC @ 25A (600VA)
or 28VAC @ 20A (560VA).
- Eight (8) Fuse Protected Outputs.
- Factory installed 3-wire line cord.
Rev. 040506
ALTV248ULCB3
- 24VAC @ 3.5A (85VA)
or 28VAC @ 3A (85VA).
- Eight (8) PTC Protected Outputs.
- Factory installed 3-wire line cord.
ALTV248175ULCB3
- 24VAC @ 7A (175VA)
or 28VAC @ 6.25A (175VA).
- Eight (8) PTC Protected Outputs.
- Factory installed 3-wire line cord.
ALTV248300ULCB3
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (280VA).
- Eight (8) PTC Protected Outputs.
- Factory installed 3-wire line cord.
ALTV248300ULCBM3
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (280VA).
- Eight (8) PTC Protected Outputs.
- Factory installed 3-wire line cord.
ALTV248600ULCB3
- 24VAC @ 25A (600VA)
or 28VAC @ 20A (560VA).
- Eight (8) PTC Protected Outputs.
- Factory installed 3-wire line cord.
More than just power.
TM
Advertisement
Related Manuals for Altronix ALTV248UL3
Summary of Contents for Altronix ALTV248UL3
-
Page 1: Installation Guide
ALTV248UL3 Series CCTV Power Supplies Installation Guide Models Include: ALTV248UL3 ALTV248ULCB3 - 24VAC @ 3.5A (85VA) - 24VAC @ 3.5A (85VA) or 28VAC @ 3A (85VA). or 28VAC @ 3A (85VA). - Eight (8) Fuse Protected Outputs. - Eight (8) PTC Protected Outputs. -
Page 2: Specifications
Overview: Altronix ALTV248UL3 Series CCTV Power Supplies provide 24VAC or 28VAC distributed via eight (8) fuse or PTC protected outputs for powering CCTV cameras, heaters and other video accessories. Eight (8) Output ALTV248UL3 Reference Chart: Altronix Model Number 24VAC 3.5A 3.5A/... -
Page 3: Installation Instructions
Code and all local codes. Use 75˚C or higher rated UL insulated wiring for connecting the unit to the mains. Replace fuses with the same type and rating (refer to Eight (8) Output ALTV248UL3 Reference Chart, pg. 2). Terminal Identification:... - Page 4 CAUTION: To reduce the risk of electric shock do not open enclosure. There are no user serviceable parts inside. Refer servicing to qualified service personnel. Fig. 1 - ALTV248UL3 Fig. 1a 24VAC or 28VAC Output 1 Follow same procedure...
- Page 5 COMMON POWER OUTPUTS 24VAC configuration Class 2 Not Wet/Class 3 Wet 28VAC configuration Class 1 non power- limited Black Lead White Lead Green Lead (ground) XFMR Voltage Selection Configuration 24VAC Input 115VAC, 50/60Hz Output 28VAC Output ALTV248UL3 Series - 5 -...
- Page 6 Fig. 3a COMMON POWER OUTPUTS Class 1 Outputs Illuminated Power Disconnect Circuit Breaker with manual reset non power- limited Black Lead White Lead Green Lead (ground) Voltage Selection Configuration 24VAC Input 115VAC, Output 50/60Hz 28VAC Output - 6 - ALTV248UL3 Series...
- Page 7 COMMON POWER OUTPUTS Class 2 Not Wet/Class 3 Wet Illuminated Power Disconnect Circuit Breaker with manual reset non power- limited Black Lead White Lead Green Lead (ground) Voltage Selection Configuration 24VAC Input 115VAC, Output 50/60Hz 28VAC Output ALTV248UL3 Series - 7 -...
- Page 8 2P & N through 8P & N Fig. 5a for outputs 2 COMMON POWER OUTPUTS through 8) Class 1 Outputs Black Lead White Green Lead Lead (ground) Voltage Selection Configuration 24VAC Output Input 115VAC, 50/60Hz 28VAC Output - 8 - ALTV248UL3 Series...
- Page 9 8P & N Fig. 6a for outputs 2 COMMON POWER OUTPUTS through 8) Class 2 Not Wet/Class 3 Wet Black Lead White Green Lead Lead (ground) Voltage Selection Configuration 24VAC Output Input 115VAC, 50/60Hz 28VAC Output ALTV248UL3 Series - 9 -...
- Page 10 Fig. 7 - ALTV248300ULM3 Fig. 7a Illuminated Power Disconnect Circuit Breaker with manual reset Transformer underneath power distribution board Green Lead (ground) Voltage Selection Configuration 24VAC Output Input 115VAC, 50/60Hz 28VAC Output - 10 - ALTV248UL3 Series...
- Page 11 Fig. 8 - ALTV248300ULCBM3 Fig. 8a Illuminated Power Disconnect Circuit Breaker with manual reset Transformer underneath power distribution board Green Lead (ground) Voltage Selection Configuration 24VAC Output Input 115VAC, 50/60Hz 28VAC Output ALTV248UL3 Series - 11 -...
- Page 12 Fig. 9 - ALTV248600UL3 Fig. 9a Illuminated Power Disconnect Circuit Breaker with manual reset MAIN FUSE Green Lead (ground) White Lead Black Lead Voltage Selection Configuration Input 115VAC, 50/60Hz 24VAC Output 28VAC Output - 12 - ALTV248UL3 Series...
- Page 13 Fig. 10 - ALTV248600ULCB3 Fig. 10a Illuminated Power Disconnect Circuit Breaker with manual reset MAIN FUSE Green Lead (ground) White Lead Black Lead Voltage Selection Configuration Input 115VAC, 50/60Hz 24VAC Output 28VAC Output ALTV248UL3 Series - 13 -...
- Page 14 Enclosure Dimensions (H x W x D): 7.25” (184.15mm) 3.625” • ALTV248UL3 (184.15mm) • ALTV248ULCB3 1.25” (31.75mm) 8.5” x 7.5” x 3.5” 3.5” (215.9mm x 190.5mm x 88.9mm) (88.9mm) 0.6” 0.6” 1.25” 6.05” (15.24mm) (15.24mm) (31.75mm) (153.67mm) 1.125” 1.125” (28.575mm) (28.575mm)
- Page 15 3.5” (88.9mm) (88.9mm) 12” (304.8mm) 12” (304.8mm) 2.5” (63.5mm) 5.88” (149.35mm) 3.5” (88.9mm) 1.13” 1” (28.7mm) (25.4mm) 7.5” 4.5” 4.5” (190.5mm) (114.3mm) (114.3mm) 4.5” (114.3mm) 1” 1” (25.4mm) (25.4mm) 5.75” 0.88” 0.88” (146.05mm) (22.35mm) (22.35mm) ALTV248UL3 Series - 15 -...
- Page 16 (267mm) (25mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIALTV248UL3 Series D03R...
