LEGRAND NUMERIC HP i 33 User Manual page 17

NOR 08:08:08 13-01 AUDIO
LOAD: 0% PBATT: 270v ALARM ON
I/P VOLT: 380 380 380v
0/P VOLT: 380 380 380v DETAIL
I/P FREQ: 50.0Hz
0/P FREQ: 50.0Hz SERVICE
STATUS: UPS NO ON
INQUIRE - ALARM OFF
NOR 08:08:08 13-01 SERVICE
MODEL: 40kVA DETAIL
LCD Ver: V001B001D001
REC Ver: V001B001D001 AUDIO
INV Ver: V001B001D001
SERIAL: 00000000000000 MAIN
INQUIRE - SERVICE
NOR 08:08:08 13-01 USER SET
TIME
CURRENT SETTING
USER KEY
USER KEY: DEFAULT
OTHER
USER SETUP
NOR 08:08:08 13-01 KEY SET
OLD KEY: 000000 UP
NEW KEY:****** DOWN
STATUS: MAINS OK CONFIRM
USER KEY SET
28
NOR 08:08:08 13-01 AUDIO
LOAD: 0% PBATT: 270v ALARM OFF
I/P VOLT: 380 380 380v
0/P VOLT: 380 380 380v DETAIL
I/P FREQ: 50.0Hz
0/P FREQ: 50.0Hz SERVICE
STATUS: UPS NO ON
INQUIRE - ALARM ON
NOR 08:08:08 13-01 SETUP
UP
USER KEY:******
EXPERT:****** DOWN
STATUS: MAINS OK CONFIRM
USER SETUP PASSWORD
NOR 08:08:08 13-01 TIME
OLD TIME: 2013-1-1 UP
08:08:08
DOWN
NEW TIME:2013-2-2
10:00:00
STATUS: MAINS OK CONFIRM
TIME SET
NOR 08:08:08 13-01 OTHER
LANGUAGE SET: Eng DEFAULT
DOWN
STATUS: MAINS OK CONFIRM
LANGUAGE SET
Alarm Information
No. Display message
1 Relay of parallel circuit must be turned on when the systems are in parallel and
PAR RLY ERR
the inverter is on. If the relay of parallel circuit cannot be turned on correctly,
UPS should be shut down (include inverter and bypass).
2
PAR COM ERR
Parallel cable disconnect when UPS is set parallel mode
3 FUSE OPEN Inverter fuse broken
4
BPS ABNORMAL Bypass input voltage or frequency excess range of Bypass
5
BPS UNTRACE
Bypass is unable to trace
6
BPS-P ERROR
Wrong phase rotation on the bypass side
7
SHARE-I FAIL
UPS in a parallel system has an unbalance load share that exceeds range
8
CAN ERROR
The CAN BUS communication fails
9 BPS SCR OPEN SCR at the bypass side is open-circuited
10 BPS SCR SHORT SCR at the bypass side is short-circuited
11 INV SCR OPEN SCR at the inverter side is open-circuited
12 INV SCR SHORT SCR at the inverter side is short-circuited
13 INV SHORT The two IGBTs up and down in the same bridge of inverter are on simultaneously
14 INV FAIL The output voltage of the inverter is out of the range of rating voltage
15 SPI COM ERR Power module internal communication loss
16
MODULE OPEN Power module pulled out or power module screws do not screwed
OUTPUT SHORT UPS output short
17
BUS FAIL The difference between positive DC bus and negative DC bus exceeds limitation
18
19 BPS I OVER Bypass current over range
20 DC HIGH The DC component of the UPS output rating power is larger than the limitation
21 OVER LOAD The UPS parallel system is confirmed to be overloaded according to the set number
22
START FAIL When the procedure of initialization is wrong, this warning will occur
Meaning
29
