QUICK SET-UP GUIDE
1000 HR-V IBB 28AH & 42AH
APPLICATIONS
3
NEW ENERGY
TO POWER
UNBOXING :
Cut the nylon belt and lift the carton box
from the top. Remove the polythene cover,
foams and lift the UPS from the lower
carton tray.
Turn on the battery circuit breaker
Connect the application input plug
to the UPS output socket, use 3-pin
6A 240 V AC plug before switching
INSTALLATION :
Step 3
Connect the UPS AC input power plug to socket before
switching the UPS on (Use 3-pin 10A or 16A 240 V AC plug
for 1 kVA.
INSTALLATION :
Step 1
Step 2
the UPS on.
www.numericups.com
2
1
Advertisement
Related Manuals for LEGRAND NUMERIC 1000 HR-V IBB 28AH
Summary of Contents for LEGRAND NUMERIC 1000 HR-V IBB 28AH
- Page 1 QUICK SET-UP GUIDE 1000 HR-V IBB 28AH & 42AH APPLICATIONS UNBOXING : Cut the nylon belt and lift the carton box from the top. Remove the polythene cover, foams and lift the UPS from the lower carton tray. INSTALLATION : Step 1 Turn on the battery circuit breaker Step 2...
- Page 2 INSTALLATION : Step 4 Press and Hold the ON/Mute button in the front panel for 2 seconds to switch the UPS on. Display status Do’s Don’ts 1. Power Switch 2. LCD Display Digital 1000 HR-V Keep at least 30 cms. Do not eat or drink clear distance between near the UPS area.
