2. Specifications

Limit deviation of the plumb up
Limit deviation of the plumb down
Accuracy of tubular level
Optics and laser plumb (zenith)
Magnification
Angle of view
Effective aperture of lens
Shortest visual field
Laser wavelength
Range of laser viewing
Laser range
Laser power
Diameter of laser spot
Error of misalignmen of optical and
vertical axis is less than
Error of misalignmen of optical and
laser axis is less than

www.geooptic.ru
VERTICAL
±2.0 мм/100м
±1.0 мм/1.5м
20" / 2 mm
inverted
25х
1° 50'
36 mm
0,8 m
635 nm
70 m
in the daytime<200m ; at night<250m
5mW
3 mm / 50 m
5"
5"
