Specifications - ADA INSTRUMENTS ProDigit 60 Operating Manual

LCD SCREEN ICONS
Up/Down Indicator - The zero line (0°) indicates the level position. The arrow indicates the current angle's position,
0
either up or down away from the level (0°).
Battery Power Icon - Indicates the amount of battery power in the unit. Replace batteries when the black power bar
disappears.
Sound / Beeper Icon - This icon appears on the screen when the beeper function is activated.
M1-M9 Memory Icon - This icon shows when the memory function is being used. Level can recall the last nine saved
measurements.
REF Indicates that the level is working in relative angle mode.
Err Indicates that the level is wrong positioned or wrong operation in calibration.
CAL1 Indicates that the digital level is in calibrating for one direction.
CAL2 Indicates that the digital level is in calibrating for the another direction.

Specifications

Recommended use
Laser class
Power supply
Angle measuring range
Optimum operation range
Accuracy of vials
Accuracy of digital display
Estimated Battery life
Indoors or Outdoors
Class2, max laser output ≤1mW
2x 1.5V AAA battteries
0 to 360°
0 to 40°
±0.029°
±0.05°(level or plumb)
±0.1°(other angles)
10 hours with alkaline batteries
9
ProDigit
MEASUREMENT FOUNDATION
60
