CIS VCC-5CL4MHS Product Specification & Operational Manual

Camera link i/f 5.01m pixels cmos b/w camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-5CL4MHS
Rev.905-0079-01
Camera Link I/F
5.01M Pixels CMOS B/W Camera
VCC-5CL4MHS
Product Specifications
& Operational Manual
CIS Corporation
©2017 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-5CL4MHS and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-5CL4MHS

Summary of Contents for CIS VCC-5CL4MHS

  • Page 1 VCC-5CL4MHS Rev.905-0079-01 Camera Link I/F 5.01M Pixels CMOS B/W Camera VCC-5CL4MHS Product Specifications & Operational Manual CIS Corporation ©2017 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Factory Settings ............................. 26 Sensor Optical Axis Accuracy .......................... 27 Dimensions ..............................28 Case for Indemnity (Limited Warranty) ......................29 CMOS Pixel Defect ............................29 Product Support ............................29 Ordering Information ............................. 29 Licensing ..............................29 ©2017 CIS Corporation. All rights reserved.

  • Page 3: Handling Precautions

    The rising time of camera power supply voltage shall be less than +10V, Max 60ms. Please avoid noises like chattering  when rising. Power supply Voltage 【V】 電源 電圧 立 ち 上 がり 時間[ ms] Voltage Rising Time 【ms】 ©2017 CIS Corporation. All rights reserved.

  • Page 4: Product Outline

    Rev.905-0079-01 Product Outline VCC-5CL4MHS is a Camera Link interfaced and 5M resolution, small industrial B/W camera module. 5.01M pixels, 2/3 type (diagonal length 11.1mm) B/W CMOS sensor is utilized. Video is output with 10 Tap 8 Bit Configuration. Entire pixels can be read out at 1/163.4s with Full Configuration output.

  • Page 5: Specifications

    ※All the specifications specified in this manual is guaranteed under performance guaranteed temperature. ※All the camera functions operate normally under operation guaranteed temperature. (22) Storage environment -25℃～+60℃ Temperature: Humidity: RH 20～80% with no condensation. ©2017 CIS Corporation. All rights reserved.

  • Page 6: Camera Input And Output Signals Specifications

    04h. (Condition: Gain 0dB) +5.0V( VCC) 100Ω FVAL Output LVAL Output DVAL Output HD74LV1GT32 ACME(RENESAS) Exposure Output Voh:3.8V(Min) Vol:0.55V( Max) 100Ω Trigger Input HD74LV1GT14 ACME(RENESAS) Vt-:0.5(Min) Vt+:1.9V(Max) IO Interface of 12pins Circular connector at rear ©2017 CIS Corporation. All rights reserved.

  • Page 7: Cmos Spectral Response

    VCC-5CL4MHS Rev.905-0079-01 4.3. CMOS Spectral Response ※The lens characteristics and illuminant characteristics are excluded. 4.4 Video Output Format (1) 10Tap 8bit Configuration Mode : 163.4fps 2450pixels ・・・ 9 10 ©2017 CIS Corporation. All rights reserved.

  • Page 8: Camera Function Settings

    Vertical flip Defective pixel correction Serial communications 9,600 baud Baud rate selection 115,200 baud ※INIT Command is excluded 0～25 Black Level Adjustment Black level adjustment (To be restored to the factory settings with INIT command). ©2017 CIS Corporation. All rights reserved.
  • Page 9 Line up and indicate the registered number of the defect pixels per reed. 5 at setup Shows the status. User data settings 2 Parameters Set any data for the user area (32 byte). All 0xFF at Save with SAVE command. Ex-Factory ©2017 CIS Corporation. All rights reserved.

  • Page 10: The List Of Preset Shutter

    ※ Please be noted that Vertical flip, horizontal flip, and partial setting command cannot be reflected right away. Dummy triggers are needed at trigger mode. ※ When gain settings + 24dB is exceeded, deterioration in the image quality is inevitable. We recommend you to evaluate it first to use. ©2017 CIS Corporation. All rights reserved.

  • Page 11: External Connector Pin Assignment

    VCC-5CL4MHS Rev.905-0079-01 External Connector Pin Assignment 6.1. 12pins Circular Connector HR10-10R-12PA(73) (HIROSE) or equivalent Pin No. Description Power Input (DC+12V) LVAL Output FVAL Output Exposure Output DVAL Output TRIGGER Inputs ©2017 CIS Corporation. All rights reserved.

  • Page 12: Camera Link Connector 12226-1100-00Pl (Sumitomo 3M)

    (2) CL・・・ To be selected when Non-PoCL frame grabber board is used. Please make sure that power is OFF when changing the switch settings. If the switch setting was changed while power is ON, it may cause malfunction or damages to the camera. ©2017 CIS Corporation. All rights reserved.

  • Page 13: Timing Chart

    Effective Line Effective Line Video Out FVAL Out LVAL Out DVAL Out V Blanking :46H Effective Line : 2048H 1Frame = 2094H 40Ｈ Exposure Out Exposure Time 1H = 2.92us 10Tap8bit Configuration mode: 163.4fps ©2017 CIS Corporation. All rights reserved.

  • Page 14: Fixed Trigger Shutter Mode

    Note that a trigger shorter than 1 frame cycle shall not be used. Effective Line Effective Line Exposure Time Effective Line : 2048H Exposure Time Delay Trigger input ignore period TRIG IN Exposure Out (SP Out) Exposure time delay ©2017 CIS Corporation. All rights reserved.

  • Page 15: Fast Fixed Trigger Shutter Mode

    Next trigger rise prohibited period : 2110H Exposure Out Exposure Time LVAL Out DVAL Out FVAL Out Effective Line : 2048H Exposure Time Delay Trigger input ignore period TRIG IN Exposure Out (SP Out) Exposure time delay ©2017 CIS Corporation. All rights reserved.

  • Page 16: Pulse Width Trigger Shutter Mode

    Exposure Out Exposure Time LVAL Out DVAL Out FVAL Out Effective Line : 2048H Exposure Time Delay① Exposure Time Delay② Trigger input ignore period TRIG IN ① ② Exposure Out (SP Out) Exposure time delay ©2017 CIS Corporation. All rights reserved.

  • Page 17: Fast Pulse Width Trigger Shutter Mode

    Exposure Out Exposure Time LVAL Out DVAL Out FVAL Out Effective Line : 2048H Exposure Time Delay① Exposure Time Delay② Trigger input ignore period TRIG IN ① ② Exposure Out (SP Out) Exposure time delay ©2017 CIS Corporation. All rights reserved.

  • Page 18: Partial Scan Mode

    Partial effective lines 1 + Partial effective lines 2 + ・・・ + Partial effective lines 8 Note that Sum total of partial effective line numbers from 1～8 (except V blanking lines) has to be less than 2048. V blanking lines at partial mode is 46H. ©2017 CIS Corporation. All rights reserved.
  • Page 19 *Especially at fixed trigger shutter mode and pulse width trigger shutter mode, input a dummy trigger first, and use the next trigger as an actual video signal. ©2017 CIS Corporation. All rights reserved.

  • Page 20: Remote Communication Function

    [¥r] [¥n] [Linefeed] [sp]=Space(0x20) [Returned value] >[sp] [Prompt + Space] 【Example of Set Command】 To set 30 to the address 21 [Send] SU[sp]21[sp]30[¥r]or[¥n] [Returned value] [¥r] [¥n] [Linefeed] [Returned value] >[sp] [Prompt + Space] ©2017 CIS Corporation. All rights reserved.
  • Page 21 Input “INIT” to restore to the initial settings. (Not saved at this point). (7) Data Save Input “SAVE” to save the camera settings [Returned value] [¥r] [¥n] [Linefeed] [Returned value] >[sp] [Prompt + Space] ©2017 CIS Corporation. All rights reserved.

  • Page 22: Pixel Defect Correction

    (2) If no effective pixel exists up next, down next, right next, or left next to the pixel to be corrected, this pixel can be registered but cannot be corrected. For example, when X1, X2, X3, and X4 are already registered as defected pixels, X can be added to be registered but it cannot be corrected. ©2017 CIS Corporation. All rights reserved.
  • Page 23 This is to delete all defected pixels data detected and registered by the users, with Address 100 and Address 101. Please execute this when you wish to redo your detection and registration from the beginning, or when you wish to restore all the registration to the factory settings. SU 103 1 to execute ©2017 CIS Corporation. All rights reserved.
  • Page 24 [ERROR] region data full: Data SUM registered by the user and the one at ex-factory exceeds the limitation for 1 CH. [ERROR] too many user defective pixels/region data full: Both of the above 2 cases occur at the same time. ©2017 CIS Corporation. All rights reserved.
  • Page 25 To show the coordinate points of out of the area, execute parameter 1 or parameter 2. These points  would be shown as minus coordinate or as the one of the out of image size. ©2017 CIS Corporation. All rights reserved.

  • Page 26: User Data Save/Read Out Function

    Data are shown with hexadecimal with space partitions. When data count more than the address are specified, error would occur and it would not be read out. 【Send】 GU[sp]200[sp] Readout Address[sp]Read out Count 【Returned value】 0xnn[sp]0xnn[sp]0xnn[sp][¥r][¥n] 【Returned value】>[sp] ©2017 CIS Corporation. All rights reserved.

  • Page 27: Factory Settings

    Horizontal Flip of the Output Image Normal Vertical Flip of the Output Image Normal Defective Pixel Correction Serial Communication Baud Rate 9600baud Gain Shutter Vertical Partial Mode OFF (2048line) Factory setting for rear switch Power Selection CL side ©2017 CIS Corporation. All rights reserved.

  • Page 28: Sensor Optical Axis Accuracy

    VCC-5CL4MHS Rev.905-0079-01 13. Sensor Optical Axis Accuracy ©2017 CIS Corporation. All rights reserved.

  • Page 29: Dimensions

    VCC-5CL4MHS Rev.905-0079-01 14. Dimensions ©2017 CIS Corporation. All rights reserved.

  • Page 30: Case For Indemnity (Limited Warranty)

    CIS Corporation, at its option, repairs or replaces it at no charge to you. Products out of warranty period will be subject to charge. CIS repairs the products as long as it is repairable. CIS shall be exempted from taking responsibility and held harmless for damages or losses incurred by the following cases.
