CIS VCC-5CXP4R Product Specification & Operational Manual

Coaxpress i/f 5m cmos color (raw) camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Rev.905-0256-Z1
CoaXPress I/F
5M CMOS Color (RAW) Camera
VCC-5CXP4R
Product Specifications
& Operational Manual
(Preliminary)
CIS Corporation
©2022 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-5CXP4R and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-5CXP4R

Summary of Contents for CIS VCC-5CXP4R

  • Page 1 Rev.905-0256-Z1 CoaXPress I/F 5M CMOS Color (RAW) Camera VCC-5CXP4R Product Specifications & Operational Manual (Preliminary) CIS Corporation ©2022 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Test Pattern Indication ..........................25 4.13. Cursor Indication ............................25 4.14. LED Operational Mode ..........................25 4.15. Camera Timing I/O ............................ 26 4.16. User ID ..............................26 4.17. Temperature Indication ..........................27 4.18. Connection Reset ............................27 ©2022 CIS Corporation. All rights reserved.
  • Page 3 6.1. Camera Dimensions ........................... 30 6.2. Optical Axis Accuracy ..........................31 Case for Indemnity (Limited Warranty) ........................32 7.1. Product Warranty ............................32 7.2. CMOS Defective Pixels ..........................32 7.3. Product Support ............................32 ©2022 CIS Corporation. All rights reserved.

  • Page 4: Handling Precautions

    □ The camera must not be used under conditions or environments other than those specified in this manual. 1.3. Disclaimers (Exception Clause) CIS should not be liable for any damages or losses if; damages or losses are caused by earthquake, lightning strike, fire, flood, or other acts of God.

  • Page 5: Product Outline

    VCC-5CX4R Rev.905-0256-Z1 Product Outline VCC-5CXP4R is a color camera with CoaxPress interface. Using 2/3”, global shutter type 5.01M pixels CMOS image sensor, frame rate reaches 163.4fps with CXP6x2 8bit. Complies with CoaXPress Version 1.1.1. Must have function ready for Machine Vision applications such as trigger shutter, ROI, Gain, black level adjustment, and defective pixels correction.

  • Page 6: Specifications

    (Cable length of power supply cable with circular connector must be less than 10m.) Power consumption 4.6W (CXP-6 2lane) [with free run] Mechanical Specifications Dimensions H: 55mm W: 55mm D: 30mm excluding projection. Weight Approx. 140g Lens mount C mount ©2022 CIS Corporation. All rights reserved.

  • Page 7: Input And Output Specifications

    □ 5.0V CMOS logic level output □ Output voltage Low: 0.55Vdc (Max.), High: 3.8Vdc (Min.) □ This is to output a timing signal of the camera. Set a signal with Line Source of Digital IO Control. ©2022 CIS Corporation. All rights reserved.

  • Page 8: External Connector Pin Assignment

    Waiting for a trigger input. Red fast blinking [12.5Hz] System error or inappropriate trigger input. ※When the number of cable connections does not meet the number of links designated with ConnectionConfig, LED will be Green/Orange fast blinking [12.5Hz] ©2022 CIS Corporation. All rights reserved.

  • Page 9: Spectral Response

    VCC-5CX4R Rev.905-0256-Z1 3.4. Spectral Response ※ Excludes characteristics of lens, optical glasses, and light source. ©2022 CIS Corporation. All rights reserved.

  • Page 10: Frame Rate

    ※Input trigger with the cycle less than the maximum frame rate explained in the above. ※Please refer to Section 3.5.1. Frame rate with Internal Sync. Mode for the time for 1 line. ※Please refer to Section 4.6.2. External Trigger Mode for details on external sync mode. ©2022 CIS Corporation. All rights reserved.

  • Page 11: Camera Functions

    Please refer to the table below to save and load settings. UserSetSelector UserSetLoad/Save Status Default UserSetLoad Load Factory settings. UserSetSave - (Not subject to execute.) UserSet0 UserSetLoad Load user settings. UserSetSave Save user settings. ©2022 CIS Corporation. All rights reserved.

  • Page 12: Link Speed And Link Count

    BayerBG12 ： Bayer 12bit (ReverseX= On, ReverseY= On) ・ ・ Bayer Pattern of VCC-5CXP4R is”RGGB” as shown as the figure to the left. ・ Ｒ Ｇ Bayer Pattern also flips when images flip in X and Y directions as explained in section 4.5. Flip.

  • Page 13: Flip

    Display screen Display screen Display screen 写体 Object 表示画面 表示画面 表示画面 ROI setting ReverseY = False ROI設定 ReverseY = True Convert OffsetY (Y0) to a OffsetY = Y0 OffsetY(Y0)を座標(Y1) coordinate (Y1) to display it に変換して表示されま Height  = W0 on the screen. す。 Y1 = 2064 – W0 – Y0 ©2022 CIS Corporation. All rights reserved.

  • Page 14: Trigger Mode

    □ The following shows timing chart and timing parameter with internal sync mode. ActualExposureDelay ExposureActive ExposureTime DataoutDelay Effective Line Effective Line Sensor ReadOut FrameActive LineActive Cxp Stream Idle Stream Data Idle Stream Data V-blanking Effective Line ©2022 CIS Corporation. All rights reserved.

  • Page 15: External Trigger Mode

    ※Please refer to specification manuals of the Host Device such as frame grabber board to know how to generate triggers. Line0: External trigger input from 6pins circular connector. Software: Input trigger with TriggerSoftware command. ※Software Trigger is valid only when TriggerActivation is Rising Edge. ©2022 CIS Corporation. All rights reserved.

  • Page 16: Fixed Trigger Shutter Mode + H Sync Trigger (Linesync)

    ExposureActive ExposureTime Idle Actual exposure period Idle Actual exposure period Idle Actual exposure period ActualExposureDelay Effective Line Effective Line DataoutDelay Sensor ReadOut FrameActive LineActive Cxp Stream Idle Stream Data Idle Stream Data Effective Line ©2022 CIS Corporation. All rights reserved.

  • Page 17: Fixed Trigger Shutter Mode + Clk Sync Trigger (Clocksync)

    Delay time from the rising edge of trigger input to ExposureActive rising [μs] Delay time from falling edge of ExposureActive to completion of exposure of Actual Exposure Delay 13.78 the sensor [μs] Dataout Delay Time from falling edge of ExposureActive to FrameActive rising [H] ©2022 CIS Corporation. All rights reserved.

  • Page 18: Pulse Width Trigger Shutter Mode + H Sync Trigger (Linesync)

    Dataout Delay Time from the falling edge of ExposureActive to FrameActive rising [H] ※For time for 1H, please refer to the time for 1 line in Section 3.5.1. Frame rate with Internal Sync. Mode. ©2022 CIS Corporation. All rights reserved.

  • Page 19: Pulse Width Trigger Shutter Mode + Clk Sync. Trigger (Clocksync)

    Dataout Delay Time from the falling edge of ExposureActive to FrameActive rising [H] ※For time for 1H, please refer to the time for 1 line in Section 3.5.1. Frame rate with Internal Sync. Mode. ©2022 CIS Corporation. All rights reserved.

  • Page 20: Restrictions On Trigger Pulse Input Timing

    Make sure to end exposure after completion of reading out to start the next. (3) With TriggerSyncMode=LineSync and TriggerActivation= RisingEdge/FallingEdge, user cannot input the next trigger during exposure period. ©2022 CIS Corporation. All rights reserved.

  • Page 21: Exposuretime

    Exposure Time =Time for 1 Line x Exposure Line Count + 13.73μ s ・ The minimum exposure line count is 1 line. ・ The maximum exposure line count is 2056 or clipped value by entire line count with partial. ©2022 CIS Corporation. All rights reserved.

  • Page 22: Gain

    Offset for Y direction of Region. Set multiple of 4. ・OffsetY: ※Make sure to set Height and OffsetY not to overlap with other regions. ※Make sure to set that the sum total of effective Region and Height will be 2056 or less. ©2022 CIS Corporation. All rights reserved.
  • Page 23 ⑤ : Total line count per frame ※ With 8 frames after changing partial scan settings, disturbed images may occur. For external trigger mode, input dummy triggers 8 times and use images taken with the 9 trigger and after. ©2022 CIS Corporation. All rights reserved.

  • Page 24: Defective Pixel Correction

    On/Off ・ DefectPixelCorrection: This is to enable or disable defective pixel correction function. ※ Please note that function controls both defective pixel correction data registered at factory and registered by user at one time. ©2022 CIS Corporation. All rights reserved.
  • Page 25 Function registers data with luminance level that exceeds the threshold value specified here. Since threshold value is 12-bit equivalent, for 8-bit images, specify a value of 16 times of signal level as a threshold value. ©2022 CIS Corporation. All rights reserved.
  • Page 26 Function registers data up to that point, outputs error, and ends operation. (2) When there is no effective pixel around the pixel to add (on the left, right, top, and bottom), user can register but cannot correct that pixel. ©2022 CIS Corporation. All rights reserved.
  • Page 27 ChannelNumber: This is to specify channel number of defective pixel correction. ・ DefectPixelChannelCount: Defective pixel count for the channel specified with ChannelNumber. ・ (Total value of defective pixel with factory count and user register count.) ©2022 CIS Corporation. All rights reserved.

  • Page 28: Test Pattern Indication

    DeviceIndicatorMode: This is to select LED operational mode out of the following 3 types. ・ ・ Active: Indication of communication status of CoaXPress. ・ ErrorStatus: OFF with normal operation. Lights only with system error. ・ Inactive: ALL LED OFF ©2022 CIS Corporation. All rights reserved.

  • Page 29: Camera Timing I/O

    ・ DeviceUserString: User can set up to 256 characters including terminal NUL letter (\0). Execute UserSetSave to save these letter strings to camera non-volatile memory. These data are not subject to “UserSetLoad” with “Default.” ©2022 CIS Corporation. All rights reserved.

  • Page 30: Temperature Indication

    Sensor (fixed) DeviceTemperature (Read Only) DeviceTemperatureSelector： This is to select the point of the device to measure temperature. ・ Fixed with sensor for VCC-5CXP4R. DeviceTemperature: This is to indicate temperature of the image sensor. ・ [Note] This is a reference temperature and not the actual temperature.

  • Page 31: Image Quality Selection Mode

    ・ BalanceRatio: This is to set gain of the selected color component from x0.00 to x8.00 per 0.01 step. If user set 1.0 to BalanceRatio of Red/Blue when BalanceRatioSelector = Red/Blue, white balance becomes disabled. Note) Make sure to execute white balance gain adjustment when camera is in operation. ・ ©2022 CIS Corporation. All rights reserved.

  • Page 32: Factory Settings

    CoaXPress connection status indication mode LineSelector Line0 Line0 LineSource FrameTrigger Trigger input DeviceUserID Character string by user (16 letters) none DeviceUserString Character string by user (256 letters) none ※ ConnectionConfig, PixelFormat, and ImageQualityMode are not subject to UserSetLoad. ©2022 CIS Corporation. All rights reserved.

  • Page 33: Dimensions

    VCC-5CX4R Rev.905-0256-Z1 Dimensions 6.1. Camera Dimensions ©2022 CIS Corporation. All rights reserved.

  • Page 34: Optical Axis Accuracy

    VCC-5CX4R Rev.905-0256-Z1 6.2. Optical Axis Accuracy ©2022 CIS Corporation. All rights reserved.

  • Page 35: Case For Indemnity (Limited Warranty)

    CIS applies defective pixel correction prior to shipment of the product. However, the number of defective pixels are subject to increase due primarily to the effect of cosmic rays. Due to this nature, CIS should not hold responsible for the natural increase of defective pixels.
