  • Page 1 VCC-FC60FR19CL Rev.900-729-31-00 English 4M Resolution CMOS Color Camera Link VCC-FC60FR19CL Product Specification & Operational Manual CIS Corporation ©2011 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Remote Communication Function .......................... 24 Initial Settings ..............................26 CMOS Optical Axis Accuracy ..........................27 Dimensions ................................. 28 Cases for Indemnity (Limited Warranty) ........................ 29 CMOS Pixel Defect ............................... 29 Product Support ..............................29 ©2011 CIS Corporation. All rights reserved.

  • Page 3: Scope Of Application

    VCC-FC60FR19CL Rev.900-729-31-00 Scope of Application This is to describe VCC-FC60FR19CL, 4M resolution, Camera Link Color CMOS Camera. All specifications contained herein are subject to change without prior notice. Reproduction in whole or in part is prohibited. 2. Handling Precautions The camera must not be used for any nuclear equipments or aerospace equipments with which mechanical failure or malfunction could result in serious bodily injury or loss of human life.

  • Page 4: Product Outline

    Voltage Rising Time [ ms ] Product Outline VCC-FC60FR19CL is a Camera Link interfaced and 4M resolution industrial color video camera module. 4M pixels CMOS sensor with diagnal length 15.930mm is utilized. Entire pixels can be read out within 1/68s at Medium Configuration output.

  • Page 5: Specification

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ©2011 CIS Corporation. All rights reserved.
  • Page 6 ※ All the specifications specified in this manual is guaranteed under Temperature performance guaranteed temperature. ※All the camera functions operate normally under operation guaranteed temperature. Humidity RH 20～80% with no condensation. (25) Storage Environment -25℃～+60℃ Temperature RH 20～80% with no condensation. Humidity ©2011 CIS Corporation. All rights reserved.

  • Page 7: Camera Output Signal Specification

    2 secounds shall be waited after turning on power to get proper camera operation. ※ +5.0V(VCC) 100Ω General Purpose Output 1～4 HD74LV1GT32ACME(RENESA) Voh:3.8V(Min) Vol:0.55V(Max) 100Ω Trigger Input, General Purpose Input 1 HD74LV1GT14ACME(RENESAS) Vt-:0.5(Min) Vt+:1.9V(Max) 12pins circular connector at rear: IO Interface ©2011 CIS Corporation. All rights reserved.

  • Page 8: Cmos Spectral Response (Representative Value)

    VCC-FC60FR19CL Rev.900-729-31-00 CMOS Spectral Response (Representative Value) 4.3. * Lens charcteristics and luminous source charcteristics are not considered. ©2011 CIS Corporation. All rights reserved.

  • Page 9: 4.4 Video Output Format

    ( 1024) ( 1024) (3) 4Tap Medium Configuration Mode : 68fps (Initial Setting) (4) 8Tap Full Configuration Mode : 135fps 2048pixel ・ ・ ・ ・ ・ ・ ・ ・ (256) (256) (256) (256) (256) (256) ©2011 CIS Corporation. All rights reserved.

  • Page 10: Function Settings

    (According to external trigger signals, the specified numbers of trigger are generated in the camera.) Internal Pulse Width Trigger Shutter Mode (According to external trigger signals, the specified numbers of trigger are generated in the camera.) Manual Gain 005&006 0～767: 0:0dB ～ 767:+12dB ©2011 CIS Corporation. All rights reserved.
  • Page 11 1Tap Base Configuration Mode (17fps) Exposure Polarity Positive Negative General Purpose Output 1, 034 HD output General Purpose Output 2, 035 FVAL output General Purpose Output 3, 036 Exposure output General Purpose Output 4 TRIG Input EN output ©2011 CIS Corporation. All rights reserved.
  • Page 12 Input 083 or 053 to save the data to EEP-ROM. ※ The data set with 2 Byte shall be set with High Byte first, then set with Low Byte. The camera rewrites the internal resister when receiving Low Byte. ©2011 CIS Corporation. All rights reserved.

  • Page 13: External Connector Pin Assignment

    *2. General Purpose Output 1～4 The following output signals can be selected by serial communication commands. Output Signals Address Data Output 1 HD output Output 2 FVAL output Output 3 Exposure output Output 4 TRIG Input EN output ©2011 CIS Corporation. All rights reserved.

  • Page 14: Camera Link Connector 12226-1100-00Pl (Sumitomo 3M)

    ・・・ Set the switch when using non-PoCL supported frame grabber board. Please make sure that the power of feeding side is OFF when changing the switch setting. If the switch setting is changed while power distribution, malfunction may occur. ©2011 CIS Corporation. All rights reserved.

  • Page 15: Timing Chart

    DVAL OUT V Blanking : 5H Effective Line : 2048 H 1Frame = 2053H(58.9ms) Exposure OUT Exposure Time(*1) (*1 ) Exposure Time : Address(009&010): Min 0(58.7ms) ～　 Max 16383 (7.4μs) 1 H = 28.667μs ©2011 CIS Corporation. All rights reserved.

  • Page 16: Horizontal Synchronous Signals Timing (2Tap Base Configuration Mode: 34Fps)

    V Blanking : 6H Effective Line : 2048 H 1Frame = 2054H(29.4ms) Exposure OUT Exposure Time (*1) (*1) Exposure Time : Address(009 &010): Min 0(29.4ms) ～　 M ax 8191 (7.4μs) 1 H = 14.333μs ©2011 CIS Corporation. All rights reserved.

  • Page 17: Horizontal Synchronous Signals Timing (4Tap Medium Configuration Mode: 68Fps) * Initial Setting

    LVAL OUT DVAL OUT 4 CLK Effective Data : 512 CLK HD OUT 80 CLK 1 H = 516 CLK Camera Link CLK : 72MHz Vertical Synchronous Signals Timing 7.6. (4Tap Medium Configuration Mode: 68fps) ©2011 CIS Corporation. All rights reserved.

  • Page 18: Horizontal Synchronous Signals Timing (8Tap Full Configuration Mode: 135Fps)

    LVAL OUT DVAL OUT 2 CLK Effective Data : 256 CLK HD OUT 80 CLK Camera Link CLK : 72MHz 1 H = 258 CLK Vertical Synchronous Signals Timing 7.8. (8Tap Full Configuration Mode: 135fps) ©2011 CIS Corporation. All rights reserved.

  • Page 19: Fixed Trigger Shutter Mode

    LVAL Out 1 Tap Base Configuration Mode 137μs LVAL Width Don' t Care 2 Tap Base Configuration Mode μs (3H period ) 4 Tap Medium Configuration Mode μs 8 Tap Full Configuration Mode μs ©2011 CIS Corporation. All rights reserved.

  • Page 20: Pulse Width Trigger Shutter Mode

    FVAL Out LVAL Out 1 Tap Base Configuration Mode 137μs LVAL Width Don' t Care 2 Tap Base Configuration Mode μs (3H period) 4 Tap Medium Configuration Mode μs 8 Tap Full Configuration Mode μs ©2011 CIS Corporation. All rights reserved.

  • Page 21: Internal Trigger Mode

    ② ：Internal Trigger Tact Timie ・・・ (Address (042&043) + 1) × 3.583us : 3.583us ～ 234.8ms Setting Conditions： ② > ①, ② > 0 ③ ：Internal Trigger Repeat Number ・・・(Address 044) + 1time (Maximum repeating number：32 Times) ©2011 CIS Corporation. All rights reserved.

  • Page 22: Partial Scan Mode

    ( Address 211&212) Partial scan effective lines 3 ③ (Address 213&214) 2047 Video Out FVAL LVAL ① ② ③ ④ ⑤ ① ： Partial Area 1 ② ： Partial Area 2 ③ ： Partial Area 3 ©2011 CIS Corporation. All rights reserved.
  • Page 23 □ Line numbers at partial scan setting, the number can be set from 1 line. However, consumption current will exceed several hundred mA so that the margin of camera power capacity shall be used. ©2011 CIS Corporation. All rights reserved.

  • Page 24: Remote Communication Function

    To save the data into EEPROM, please refer to Section 5. Function Settings. C is the code to send the data back from the camera. Note: Do not set code C when sending the data from PC side. ©2011 CIS Corporation. All rights reserved.
  • Page 25 Data Save Input data 083 or 053 into the address 255 to save the data to EEP-ROM. Initial Settings Input data 083 or 053 into the address 254 to return to the initial settings. ©2011 CIS Corporation. All rights reserved.

  • Page 26: Initial Settings

    General Purpose Output 3 Exposure Output General Purpose Output 4 TRIG Input EN Output Camera Link SP Output Exposure Output Camera Link DVAL Output DVAL Output Initial Setting of camera rear switch Power feeding selection CL side ©2011 CIS Corporation. All rights reserved.

  • Page 27: Cmos Optical Axis Accuracy

    0.6 phai to the center of the lens mount. Inclination of the effective pixels “Theta”? to the datum plane A is ?? ±1° Datum Plane A *)Dimensions from datum plane A to the center of the lens mount 910-017-00-00 (Unit:mm) ©2011 CIS Corporation. All rights reserved.

  • Page 28: Dimensions

    2-M4 Depth 4 (same as the ±0.15 (11) (11) back side) 999-556-00-01 * )Screw length of the lens from the lens mount surface shall be under 4mm. (Unit:mm) And protruding portion shall be under 4mm. ©2011 CIS Corporation. All rights reserved.

  • Page 29: Cases For Indemnity (Limited Warranty)

    On very rare occasions, however, CMOS pixel defects might be noted with time of usage of the products. Cause of the CMOS pixel defects is the characteristic phenomenon of CMOS itself and CIS is exempted from taking any responsibilities for them. Should you have any questions on CMOS pixel defects compensation, please contact us.
