CIS VCC-G20X30B Product Specification & Operational Manual

Analog i/f 29mm cubic xga analog b/w camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

VCC-G20X30B
Rev. 900-731-31-00
Analog I/F
29mm Cubic XGA
Analog B/W Camera
VCC-G20X30B
Product Specification
& Operational Manual
CIS Corporation
©2012 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-G20X30B and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-G20X30B

Summary of Contents for CIS VCC-G20X30B

  • Page 1 VCC-G20X30B Rev. 900-731-31-00 Analog I/F 29mm Cubic XGA Analog B/W Camera VCC-G20X30B Product Specification & Operational Manual CIS Corporation ©2012 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    7.2.4. 1/4 Partial Scan Mode ......................16 8. CCD OPTICAL ACCURACY ....................... 17 9. DIMENSIONS ..........................18 10. CASES FOR INDEMNITY (LIMITED WARRANTY) ................19 11. CCD PIXEL DEFECT ........................19 12. PRODUCT SUPPORT ........................19 ©2012 CIS Corporation. All rights reserved.

  • Page 3: Scope Of Application

    VCC-G20X30B Rev. 900-731-31-00 1. Scope of Application This is to describe VCC-G20X30B, XGA B/W CCD camera. All specifications contained herein are subject to change without prior notice. Reproduction in whole or in part is prohibited. 2. Handling Precautions The camera must not be used for any nuclear equipments or aerospace equipments with which mechanical failure or malfunction could result in serious bodily injury or loss of human life.

  • Page 4: Product Outline

    VCC-G20X30B Rev. 900-731-31-00 3. Product Outline VCC-G20X30B is a high-resolution industrial B/W camera module utilizing a 1/3-inch PS IT CCD. 800K pixels CCD image sensor with on-chip micro-lenses realizes high sensitivity and high resolution. Key Features □ HD/VD sync input or Trigger input are valid.

  • Page 5: Specification

    Approx. 45 g Lens mount C mount (Refer to overall dimension drawing) Optical axis accuracy Refer to drawing for CCD Optical Axis Accuracy (Clause 8) 0～12dB (over guaranteed value) Gain variable range Gamma 1 (fixed) ©2012 CIS Corporation. All rights reserved.
  • Page 6 ±Y, ±Z, 6 directions. (without package) Temperature Operation guaranteed: -5℃～+45℃ Performance guaranteed: 0℃～+40℃ Operation environment RH 20～80% with no condensation Humidity Temperature -25 ℃ ～ +60℃ Storage environment RH 20～80% with no condensation Humidity ©2012 CIS Corporation. All rights reserved.

  • Page 7: Camera Input/Output Signal Specification

    10kΩ (Pull Up) Video signal VS output 1.0V (p-p), Sync. Negative, 75Ω unbalanced White clip level: 820 ± 70 mVp-p Setup level: 20 ± 15 mVp-p (Gain 0dB) SYNC level: 290 ± 50 mVp-p ©2012 CIS Corporation. All rights reserved.

  • Page 8: Ccd Spectral Response (Representative Value)

    VCC-G20X30B Rev. 900-731-31-00 4.3. CCD Spectral Response (Representative Value) ©2012 CIS Corporation. All rights reserved.

  • Page 9: Function Settings

    Fixed trigger shutter mode (SYNC non reset mode) Pulse width trigger shutter mode (SYNC reset mode) Pulse width trigger shutter mode (SYNC non reset mode) ※ Do not set other than the above settings. Indicates initial setting position. ©2012 CIS Corporation. All rights reserved.
  • Page 10 This function is useful when sensitivity with regular exposure time is not sufficient or when indicating the locus of moving object. External HD External VD (1V min) Exposure Period Video Output 768H (Full Frame) WEN Output ©2012 CIS Corporation. All rights reserved.
  • Page 11 Set value by trigger pulse width: 9μs ～ 250ms (Actual time = trigger pulse width + 5μs) Trigger Input Pulse Width: 4μs～250ms Exposure Time Setting Time by (Trigger Pulse Width + 5μs) External HD External VD 10μs～65ms Video Output 768H (Full Frame) WEN Output ©2012 CIS Corporation. All rights reserved.
  • Page 12 Low Level (Max 0.5V) SW9: OFF and Partial IN:’H’ SW9: ON or Partial IN:’L’ At SW4 OFF Full Frame Scan Mode 1/2 Partial Scan Mode At SW4 ON Binning Scan Mode 1/4 Partial Scan Mode ©2012 CIS Corporation. All rights reserved.
  • Page 13 Rev. 900-731-31-00 Changing 75ohm HD/VD input impedance HD/VD input impedance 10kΩ HD/VD input impedance 75Ω Changing HD/VD input and output SW10 HD/VD output HD/VD input (Internal/External sync is recognized automatically.) Indicates the factory setting position ©2012 CIS Corporation. All rights reserved.

  • Page 14: External Connector Pin Assignment

    VCC-G20X30B Rev. 900-731-31-00 6. External Connector Pin Assignment 12pins Circular Connector SNH-10-12(RPCB) (SAMWOO) Pin No. Power IN +12V Video Out HD In/Out VD In/Out Partial IN WEN Out Trigger In ©2012 CIS Corporation. All rights reserved.

  • Page 15: Timing Chart

    7.2.2. Binning Scan Mode １V = 398H (59.35Hz) 1H = 42.33μs Camera VD CCD Output Transmit Black Effective Lines Invalid Video Output Vertical Blanking Video Active Period 370H WEN Output (Normal Shutter Mode = “H” Level) ©2012 CIS Corporation. All rights reserved.

  • Page 16: 1/2 Partial Scan Mode

    １V = 199H (118.7Hz) 1H = 42.33μs Camera VD CCD Output Transmit High Speed Transmit Effective Lines High Speed Transmit Video Output Vertical Blanking Video Active Period 136H WEN Output (Normal Shutter Mode = “H” Level) ©2012 CIS Corporation. All rights reserved.

  • Page 17: Ccd Optical Accuracy

    ?? ±0.5° The center of effective pixels shall be within f 0.6 to the center of lens mount. (*) Dimension from datum plane to the center of lens mount. 910-015-00-00 (Unit : mm) ©2012 CIS Corporation. All rights reserved.

  • Page 18: Dimensions

    ? : C mount screws comply with ANSI/ASME B1.1, 1-32UN (2B). ? : Screw length from C mount lens surface shall be under 6mm and the protruding portion shall be less than 10mm. 999-534-00-00 (Unit:mm) ©2012 CIS Corporation. All rights reserved.

  • Page 19: Cases For Indemnity (Limited Warranty)

    After delivery, on the rare occasion, CCD pixel defects might be noted with time of usage of the products. The cause of the CCD pixel defects is the characteristic phenomenon of CCD itself and CIS shall be exempted from taking responsibility on it.
