CIS VISION:elite VCC-GM60FV11CL Product Specification & Operational Manual

125m ultra high resolution b/w camera link
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-GM60FV11CL
Rev. 900-713-32
English
125M Ultra High Resolution
B/W Camera Link
VCC-GM60FV11CL
Product Specification
& Operational Manual
CIS Corporation
©2012 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISION:elite VCC-GM60FV11CL and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VISION:elite VCC-GM60FV11CL

Summary of Contents for CIS VISION:elite VCC-GM60FV11CL

  • Page 1 VCC-GM60FV11CL Rev. 900-713-32 English 125M Ultra High Resolution B/W Camera Link VCC-GM60FV11CL Product Specification & Operational Manual CIS Corporation ©2012 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    12. Image Synthesis ········································································································ 22 13. CCD Optical Axis Accuracy ···························································································· 24 14. Dimensions ·············································································································· 25 15. Cases for Indemnity (Limited Warranty) ··········································································· 26 16. CCD Pixel Defect ········································································································ 26 17. Product Support ········································································································ 26 ©2012 CIS Corporation. All rights reserved.

  • Page 3: Scope Of Application

    AC leaks from the connected devices may cause damages or destroy the camera. Do not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power  supply voltage may cause damages or malfunction of the camera. ©2012 CIS Corporation. All rights reserved.
  • Page 4 Therefore, differences between right screen and left screen could be seen depending on the usage conditions (shooting conditions /temeperature conditions and so on). CIS trys its best to adjust this differences but please be noted it would not be perfect. Voltage Rising Time [ ms ]...

  • Page 5: Product Outline

    ※ Please ask us for the details on image synthesis software. Verified Frame Grabber Board □ TB-6S-LX150T-GB-R (Tokyo Electron Device LTD).  ※ Please ask Tokyo Electron Device Ltd for the details on the frame grabber board. ©2012 CIS Corporation. All rights reserved.

  • Page 6: Specification

    5.5W (At DC +12V IN, normal mode, and partial scan mode) Refer to overall dimension drawing. Dimensions (11) H:55mm W:55mm D:84.5mm (excluding projection.) Mass Approx. 510g (12) Lens mount C Mount (Refer to overall dimension drawing) (13) ©2012 CIS Corporation. All rights reserved.
  • Page 7 RH 20～80% with no condensation. Humidity Temperature -25℃～+60℃ Storage Environment (21) Humidity RH 20～80% with no condensation. ※ In this Specification, we describe pixel shifting technology as “SOPT: Spatial Offsetting Pickup Technique”. ©2012 CIS Corporation. All rights reserved.

  • Page 8: Camera Output Signal Specification

    : Under 08h for both horizontal and vertical. (Conditions: Gain 0dB) Leval differences At Digital 8bit : Under 03h (Conditions: Gain 0dB) between right and left ※ 2 secounds shall be waited after turning on power to get proper camera operation. ©2012 CIS Corporation. All rights reserved.

  • Page 9: Ccd Spectral Response (Representative Value)

    ※ Lens charcteristics and luminous source charcteristics are not considered. 4.4. Video Output Format ・ 2-Taps Output ・ Area of interest Width : 2448 Height : 2058 Offset X : 0 Offset Y : 12 ©2012 CIS Corporation. All rights reserved.

  • Page 10: Function Settings

    Shutter Speed = (2078 - (009&010))×32.07μs+27.73μs Max Data = 2078 0: Positive Input Trigger Polarity 1: Negative Input 0: Camera Link Trigger Input 1: 12pins Circular Connector 0: 8bit Output Data Output Data Select 1: 10bit Output Data ©2012 CIS Corporation. All rights reserved.
  • Page 11 ※ In this Specification, we describe pixel shifting technology as “SOPT: Spatial Offsetting Pickup Technique”. ※ The data set with 2 Byte shall be set with High Byte first, then set with Low Byte. The camera rewrites the internal resister when receiving Low Byte. ©2012 CIS Corporation. All rights reserved.

  • Page 12: External Connector Pin Assignment

    6.2. 26 pins Camera Link Connector 12226-1100-00 PL (SUMITOMO 3M) Pin No. Pin No. 名 称 XCLK- XCLK+ SerTC+ SerTC- SerTFG- SerTFG+ CC1- (Trigger IN -) CC1+ (Trigger IN +) NA (CC2+) NA (CC2-) NA (CC3-) NA (CC3+) NA (CC4+) NA (CC4-) ©2012 CIS Corporation. All rights reserved.

  • Page 13: Timing Chart

    2Tap Output 7.2. Full Frame Scan Mode Video Output 2058 H 21 H 2058 H (CCD Read Out Signal) 2075 2076 2077 2078 2079 LVAL Output DVAL Output FVAL Output 12 H Total = 2079H ©2012 CIS Corporation. All rights reserved.

  • Page 14: Fixed Trigger Shutter Mode

    ( G ) ( Exposure Time ) Exposure Output （Ｆ） （Ｂ） Exposure Time ( Register Set Value ) Exposure Time ( Register Set Value ) Video Output ( E ) ( F ) （Ｂ） DVAL Output ©2012 CIS Corporation. All rights reserved.

  • Page 15: Pulse Width Trigger Shutter Mode

    Exposure Time （Ｂ） ( Pulse Width ) ( Pulse Width ) ( Pulse Width ) ( Video Output ( C )) ( D ) ( A ) ( B ) Video Output DVAL Output ©2012 CIS Corporation. All rights reserved.

  • Page 16: Partial Scan Mode Details

    1219 H 26 fps ・ ・ ・ ・ 1026 H 1391 H 22 fps ・ ・ ・ ・ 1200 H 1507 H 21 fps ・ ・ ・ ・ 2058 H 2079 H 15 fps ©2012 CIS Corporation. All rights reserved.

  • Page 17: Remote Communication Function

    To save the data into EEPROM, please refer to Section 5. Function Settings. C is the code to send the data back from the camera. Note: Do not set code C when sending the data from PC side. ©2012 CIS Corporation. All rights reserved.

  • Page 18: Initial Settings

    Frame ID ON/OFF SOPT Mode 45M Mode SOPT Standby Standby OFF SOPT Long Term Exposure 098&099 2079: OFF Mode ※ In this Specification, we describe pixel shifting technology as “SOPT: Spatial Offsetting Pickup Technique”. ©2012 CIS Corporation. All rights reserved.

  • Page 19: Sopt Control

    Software Trigger Mode Standby Send Control Command 000000W063002 Software Trigger Output Send Control Command Camera output 000000W061000 45M Mode 9pcs. 125M Mode 25pcs. Capturing Images Image synthesis Repeat ? Cancel Standby Send Control Command 000000W063000 Completion ©2012 CIS Corporation. All rights reserved.

  • Page 20: External Trigger Control Sequence

    000000W062000 000000W062001 External Trigger Mode Standby Send Control Command 000000W063001 External Trigger Output Camera Output 45M Mode 9pcs 125M Mode 25pcs Capturing Images Image Synthesis Repeat ? Cancel Standby Send Control Command 000000W063000 Completion ©2012 CIS Corporation. All rights reserved.

  • Page 21: To Operate Sopt With Software Trigger (45M Mode)

    (2) Partial scan mode can not be used at SOPT Mode. (3) Pulse width trigger mode can not be used at SOPT Mode. Shutter values should be set at the address 002. (4) Set the internal trigger cycle with address 098 & 099. ©2012 CIS Corporation. All rights reserved.

  • Page 22: Image Synthesis

    (0,0) (0,0) (0,0) (0,0) (0,0) 21st 22nd 23rd 24th 25th pixel pixel pixel pixel pixel (0,0) (0,0) (0,0) (0,0) (0,0) 21st Image 25th Image 22nd Image 24th Image 23rd Image ©2012 CIS Corporation. All rights reserved.
  • Page 23 Frame ID Data (8bit) ： SOPT OFF Image ・・・ 00(Hex) SOPT ON Image ・・・ 01(Hex) ～ 19(Hex) 45M Mode 01(Hex) ～ 7D(Hex) 125M Mode Address ： 060 Data ： 0 ・・・ Frame ID OFF 1 ・・・ Frame ID ON ©2012 CIS Corporation. All rights reserved.

  • Page 24: Ccd Optical Axis Accuracy

    Inclination of the effective pixels “Theta” Datum Plane A to the datum plane A is ?? ±1.0° *)Dimensions from datum plane A to the center of the lens mount. 910-018-00-00 (Unit:mm) ©2012 CIS Corporation. All rights reserved.

  • Page 25: Dimensions

    VCC-GM60FV11CL Rev. 900-713-32 14. Dimensions ©2012 CIS Corporation. All rights reserved.

  • Page 26: Cases For Indemnity (Limited Warranty)

    On very rare occasions, however, CCD pixel defects might be noted with time of usage of the products. Cause of the CCD pixel defects is the characteristic phenomenon of CCD itself and CIS is exempted from taking any responsibilities for them. Should you have any questions on CCD pixel defects compensation, please contact us.
