  • Page 1 VCC-FC21U19PCL Rev.900-762-31 English Camera link I/F 2M Resolution CMOS Color (RAW) PoCL VCC-FC21U19PCL Product Specification & Operational Manual CIS Corporation ©2016 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Remote Communication Function ........................21 Initial Settings ..............................22 CMOS Optical Axis Accuracy ..........................23 Dimensions ..............................24 Cases for Indemnity (Limited Warranty) ......................25 CMOS Pixel Defect ............................25 Product Support ..............................25 ©2016 CIS Corporation. All rights reserved.

  • Page 3: Scope Of Application

    VCC-FC21U19PCL Rev. 900-762-31 Scope of Application This is to describe VCC-FC21U19PCL, 2M resolution, Power over Camera Link Color CMOS Camera. All specifications contained herein are subject to change without prior notice. Reproduction in whole or in part is prohibited. 2. Handling Precautions The camera must not be used for any nuclear equipments or aerospace equipments with which mechanical failure or malfunction could result in serious bodily injury or loss of human life.
  • Page 4 Especially when the read-out line is set in the range of 100 lines to 1 line, heat dissipation is recommended to install the camera. Installation recommended. ・ Install the camera to the place with ambient temperature under 40 ℃. ・ Install the camera to a metallic component. ©2016 CIS Corporation. All rights reserved.

  • Page 5: Product Outline

    Rev. 900-762-31 Product Outline VCC-FC21U19PCL is a Power over Camera Link interfaced and 2M resolution industrial color video camera module. 2M pixels CMOS sensor with diagonal length 12.775mm is utilized. Entire pixels can be read out within 1/140s at Medium Configuration output.
  • Page 6 (24) Operation Environment ※ All the camera functions operate normally under operation guaranteed temperature. Humidity RH 20～80% with no condensation. -25℃～+60℃ Temperature (25) Storage Environment RH 20～80% with no condensation. Humidity ©2016 CIS Corporation. All rights reserved.

  • Page 7: Camera Output Signal Specification

    ±00Fh. At Digital 8bit : Both horizontal and vertical should be under 03h. (Condition: Gain 0dB) 2 seconds shall be waited after turning on power to get the camera operate properly. ※ ©2016 CIS Corporation. All rights reserved.

  • Page 8: Cmos Spectral Response (Representative Value)

    VCC-FC21U19PCL Rev. 900-762-31 CMOS Spectral Response (Representative Value) 4.3. * Lens characteristics and luminous source characteristics are not considered. ©2016 CIS Corporation. All rights reserved.

  • Page 9: 4.4 Video Output Format

    Rev. 900-762-31 4.4 Video Output Format (1) 2Tap Base Configuration Mode : 70fps 2048pixel ・・・ (2) 4Tap Medium Configuration Mode : 140fps (Initial Setting) 2048pixel ・・・ (3) 8Tap Full Configuration Mode : 280fps 2048pixel ・・・ ©2016 CIS Corporation. All rights reserved.

  • Page 10: Function Settings

    10bit output (10bit cannot be output at 8Tap Full Configuration mode.) Partial Scan Mode Full Frame Scan Mode Partial Scan Mode Output image flip vertical Normal Flip Vertical Gain CC Control ON/OFF ON (Gain and WB can be controlled via CC2, CC3, and CC4.) ©2016 CIS Corporation. All rights reserved.
  • Page 11 Set the data of the address 003 to 004. Manual White Balance G 050&051 0～767: :0dB ～ 767:+12dB Set the data of the address 003 to 004. Cursor Indication ON/OFF 0～2047: Cursor X Address 061&060 0～1087: Cursor Y Address 063&062 ©2016 CIS Corporation. All rights reserved.
  • Page 12 Input 083 to save the data to EEP-ROM. ※ The data set with 2 Byte shall be set with High Byte (even address) first, then set with Low Byte (odd address). The camera rewrites the internal resister when receiving Low Byte. ©2016 CIS Corporation. All rights reserved.

  • Page 13: External Connector Pin Assignment

    ※Power to the camera shall be supplied only via CN1 of the Base connector side. CN1 power line of the Medium or Full configuration connector side shall be kept open. Do not plug and unplug the camera link cables since it may cause the camera malfunction. ©2016 CIS Corporation. All rights reserved.

  • Page 14: Timing Chart

    Effective Line Video Out (Read Out Pulse) FVAL Out LVAL Out DVAL Out V Blanking : 16H Effective Line : 1088H 1Frame = 1104H(14.242ms) SP Out(Exposure Out) Exposure Time( Address (036&037)) 1H = 12.9us ©2016 CIS Corporation. All rights reserved.

  • Page 15: Horizontal Synchronous Signals Timing (4Tap Medium Configuration Mode: 140Fps) *Initial Setting

    Effective Line Video Out (Read Out Pulse) FVAL Out LVAL Out DVAL Out V Blanking : 16H Effective Line : 1088H 1Frame = 1104H(7.121ms) SP Out(Exposure Out) Exposure Time( Address (036&037)) 1H = 6.45us ©2016 CIS Corporation. All rights reserved.

  • Page 16: Horizontal Synchronous Signals Timing (8Tap Full Configuration Mode: 280Fps)

    Effective Line Video Out (Read Out Pulse) FVAL Out LVAL Out DVAL Out V Blanking : 16H Effective Line : 1088H 1Frame = 1104H(3.560ms) SP Out(Exposure Out) Exposure Time( Address (036&037)) 1H = 3.225us ©2016 CIS Corporation. All rights reserved.

  • Page 17: Fixed Trigger Shutter Mode

    Effective Line : 1088H (Trigger input ignore period) TRIG Input EN TRIG IN SP Out (Exposure Out) 2Tap Base Configuration Mode max 12.9us 4Tap Medium Configuration Mode max 6.45us 8Tap Full Configuration Mode max 3.225us ©2016 CIS Corporation. All rights reserved.

  • Page 18: Pulse Width Trigger Shutter Mode

    Exposure Time Effective Line : 1088H (Trigger input ignore period) TRIG IN SP Out (Exposure Out) 2Tap Base Configuration Mode max 12.9us 4Tap Medium Configuration Mode max 6.45us 8Tap Full Configuration Mode max 3.225us ©2016 CIS Corporation. All rights reserved.

  • Page 19: Partial Scan Mode

    FVAL LVAL ① ② ③ ④ ⑤ ① ： V Blanking Line Number ② : Partial Area 1 ③ ： Partial Area 2 ④ ： Partial Area 3 ⑤ ： Total Frame Line Number ©2016 CIS Corporation. All rights reserved.
  • Page 20 (Max:Full Frame) Line numbers at partial scan setting can be set from 1 line. However, consumption current will □ increase several hundreds mA more so that the margin of camera power capacity shall be considered. ©2016 CIS Corporation. All rights reserved.

  • Page 21: Remote Communication Function

    To save the data into EEPROM, please refer to Section 5. Function Settings. C is the code to send the data back from the camera. Note: Do not set code C when sending the data from PC side. ©2016 CIS Corporation. All rights reserved.

  • Page 22: Initial Settings

    Normal Shutter Mode (Trigger OFF) Trigger Polarity Positive Output Data Selection 8bit output Partial Scan Mode Full Frame Scan Mode Output Image Flip Vertical Normal Gain CC Control ON/OFF Baud Rate 9600bps Camera Mode 4Tap Medium Configuration Mode ©2016 CIS Corporation. All rights reserved.

  • Page 23: Cmos Optical Axis Accuracy

    VCC-FC21U19PCL Rev. 900-762-31 CMOS Optical Axis Accuracy ©2016 CIS Corporation. All rights reserved.

  • Page 24: Dimensions

    VCC-FC21U19PCL Rev. 900-762-31 Dimensions ©2016 CIS Corporation. All rights reserved.

  • Page 25: Cases For Indemnity (Limited Warranty)

    On very rare occasions, however, CMOS pixel defects might be noted with time of usage of the products. Cause of the CMOS pixel defects is the characteristic phenomenon of CMOS itself and CIS is exempted from taking any responsibilities for them. Should you have any questions on CMOS pixel defects compensation, please contact us.
